Robertshaw Spark Ignition Control, Lockout, PrePurge 780-003 - main

Spark Ignition Control, Lockout, PrePurge

  • Mfr # 780-003

  • Zoro # G3121797

product price: $236.99
/ea
Free Shipping & Returns

Key Features

Amps AC
1.5 A
Retries
3
Electrical Ratings
Combined Load 1.5 at .4 PF, Flame Sensor Current .7 mA DC @ 25C / 24V AC, Main valve 1 amp at .5 PF, Pilot valve 1 amp at .5 PF
Lockout Time (Sec.)
Three 60 Second Valve Trials Interrupted By A Five Minute Purge Cycle Before 100 Percent Lockout
Height (In.)
5 1/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
780-003
Zoro #
G3121797
UPC #
662013642518
Country of Origin
Mexico

Dimensions

Height (In.)
5 1/8 in
Depth (In.)
1 1/4 in
Width (In.)
3 21/32 in
Overall Depth
1 1/4 in
Overall Width
3 5/8 in
Overall Height
5 1/8 in

Details

Amps AC
1.5 A
Retries
3
Electrical Ratings
Combined Load 1.5 at .4 PF, Flame Sensor Current .7 mA DC @ 25C / 24V AC, Main valve 1 amp at .5 PF, Pilot valve 1 amp at .5 PF
Lockout Time (Sec.)
Three 60 Second Valve Trials Interrupted By A Five Minute Purge Cycle Before 100 Percent Lockout
For Use With
Residential and Commercial Heating Equipment
Electrical Connections
Terminals
Item
Ignition Control
Includes
Vent Damper Adaptor Assembly
Control Volts
24 V AC
Pressure Setting Range (In. WC)
3.5
Gas Type
NG/LP
Prepurge Time (Sec.)
45 sec
Voltage
24
Type
Spark Ignition
Product Type
Ignition Control
Input Voltage
24V AC
Replacement Type
Universal
Pre-Purge Time
45 sec
Control Voltage
24V AC
Compatible with Brand
Butler, Commerical Appliance, Email Ltd, Honeywell, IBM, Johnson Controls, Johnstone Supply, Robertshaw, Uni-Line
Series
780
Lock Out Time
1 min
Electrical Connection Type
Screw Terminals
Frequency
50/60 Hz
Ignition Cycle Time
60 seconds
Compatible with Series
Universal
Maximum Operating Temperature
175 Degrees F
Thermostat Anticipator Setting
Thermostat Anticipator
OEM Replacement Part Number
100-802-05, 100-831-04, 100-831-54, 100-831-66, 233-61160-00A, 63539, 64251, 780-736, G770LHC-1, G770MHC-1, G770NHC-1, L38-366, S860C1000, S860D1009, S860D1017, S8610H1020, SJ4002-104, SJ4009-400, SP745-PU-3-60-5
Number of Retries
3
Main Valve Current Output
1.5 A
Flame Sensor Current Output
0.7 mA
Minimum Operating Temperature
-40 Degrees F
For Fuel Type
LP, Natural Gas

Description

Ignition Control, Product Type Ignition Control, Maximum Operating Temperature 175 Degrees F, Minimum Operating Temperature -40 Degrees F, Lock Out Time 1 min, Pre-Purge Time 45 sec, Number of Retries 3, Main Valve Current Output 1.5 A, Flame Sensor Current Output 0.7 mA, Ignition Cycle Time 60 seconds, Automatic Reset Time Not Applicable, Compatible with Series Universal
