Shaft Collar, Stainless Steel, 1-Piece, Plain

  • Mfr # MCL-18E-P
  • Zoro # G508678944
product price:
$
20.39
/ea

Key Features

Screw Material
Stainless Steel
Width Tolerance
+0.076/-0.254 mm
System of Measurement
Metric with Inch Bore
Bore Tolerance
+0.0020/+0.0005 in
Standards
Conflict Minerals Compliant, DIN 912 12.9, ISO 9001:2015 Certified, REACH Compliant, RoHS3 Compliant
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
MCL-18E-P
Zoro #
G508678944
UPC #
-
Country of Origin
United States
Screw Material
Stainless Steel
System of Measurement
Metric with Inch Bore
Bore Tolerance
+0.0020/+0.0005 in
Standards
Conflict Minerals Compliant, DIN 912 12.9, ISO 9001:2015 Certified, REACH Compliant, RoHS3 Compliant
Screw Seating Torque
3.9 N-m
Item
Shaft Collar
Collar Material
Plastic
Collar Material Finish
Plain
Included Screws
Clamp Screw
Minimum Operating Temperature
-10 Degrees F
Screw Material Finish
Bright
Maximum Operating Temperature
185 Degrees F
Bore Type
Round
Collar Material Grade
Acetal
Resistance Properties
Corrosion-Resistant
Shaft Locking Type
Clamp-On
Collar Construction
1-Piece
Screw Location from Center
19 mm
Screw Material Grade
18-8 300 Series
Shaft Tolerance
+0.0000/-0.0005 in

Description

Shaft Collar, System of Measurement Metric with Inch Bore, Bore Type Round, Bore Diameter 1 1/8 in, Bore Thread Size Not Applicable, Collar Outside Diameter 48 mm, Inside Height to Flat Not Applicable, Clearance Diameter 54.7 mm, Collar Width 15 mm, Collar Material Plastic, Keyway Width Not Applicable, Collar Material Grade Acetal, Keyway Depth Not Applicable, Thread Direction Not Applicable, Center to Lever Top Not Applicable, Collar Construction 1-Piece, Screw Material Stainless Steel
