- MFR #
- PM010 PLAA 622
- Zoro #
- G223524694
- UPC #
- 197163385478
- Country of Origin
- Mexico
- Latch Bolt/Dead Bolt
- Latch Bolt
- Hand Orientation
- Non-Handed
- Strike Type
- Curved Lip
- Knob/Handle Material
- Zinc
- Visual Indicator Location
- Inside/Outside
- Voltage
- 12/24V DC
- Key Material
- Nickel Silver
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- Performance Grade
- 1
- Failure Mode
- Fail Safe or Fail Secure
- Key Type
- Not Keyed
- Keyway Type
- S123
- Backset
- 2 3/4 in
- Lockset Style
- Playa
- Lockset Function ANSI Code
- F01
- Number of Pins
- 0
- Locking/Unlocking Access - Outside
- Not Lockable
- Includes
- Dust Box
- ADA Compliant
- Yes
- Mortise/Cylindrical
- Mortise
- Lockset Type
- Mechanical
- Number of Keys
- 0
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- ANSI/BHMA Finish
- Black Painted
- Includes Core
- Core Included
- ANSI Grade
- 1
- Locking/Unlocking Access - Inside
- Not Lockable
- Item
- Door Lockset
- Fire Rating
- 3 hr
- Visual Indicator Message
- No Message
- Ligature-Resistant
- Not Ligature-Resistant
