- MFR #
- PM056P LATN 622
- Zoro #
- G223524380
- UPC #
- 197163386253
- Country of Origin
- Mexico
- Backset
- 2 3/4 in
- Latch Bolt/Dead Bolt
- Latch Bolt
- Fire Rating
- 3 hr
- Lockset Style
- Latitude
- Key Material
- Nickel Silver
- Locking/Unlocking Access - Inside
- Thumb Turn
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- Lockset Type
- Mechanical
- Key Type
- Keyed Different
- ANSI/BHMA Finish
- Black Painted
- ANSI Grade
- 1
- Item
- Door Lockset
- Includes Core
- Core Included
- Hand Orientation
- Non-Handed
- ADA Compliant
- Yes
- Locking/Unlocking Access - Outside
- Keyway
- Keyway Type
- S123
- Number of Pins
- 6
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Visual Indicator Location
- Inside/Outside
- Mortise/Cylindrical
- Mortise
- Includes
- Dust Box
- Voltage
- 12/24V DC
- Failure Mode
- Fail Safe or Fail Secure
- Knob/Handle Material
- Zinc
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- Strike Type
- Curved Lip
- Performance Grade
- 1
- Visual Indicator Message
- No Message
- Cylinder Core Type
- Conventional Core Cylinder
- Ligature-Resistant
- Not Ligature-Resistant
