- MFR #
- PM056P LATN 626
- Zoro #
- G023523675
- UPC #
- 197163386260
- Country of Origin
- Mexico
- Keyway Type
- S123
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- ANSI/BHMA Finish
- Satin Chromium-Plated
- Voltage
- 12/24V DC
- Hand Orientation
- Non-Handed
- Strike Type
- Curved Lip
- Fire Rating
- 3 hr
- ANSI Grade
- 1
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- Includes Core
- Core Included
- Lockset Type
- Mechanical
- Key Material
- Nickel Silver
- Visual Indicator Location
- Inside/Outside
- Locking/Unlocking Access - Outside
- Keyway
- Mortise/Cylindrical
- Mortise
- Knob/Handle Material
- Zinc
- Failure Mode
- Fail Safe or Fail Secure
- Key Type
- Keyed Different
- Backset
- 2 3/4 in
- Performance Grade
- 1
- Latch Bolt/Dead Bolt
- Latch Bolt
- Lockset Style
- Latitude
- Number of Pins
- 6
- Includes
- Dust Box
- Locking/Unlocking Access - Inside
- Thumb Turn
- Item
- Door Lockset
- ADA Compliant
- Yes
- Ligature-Resistant
- Not Ligature-Resistant
- Cylinder Core Type
- Conventional Core Cylinder
- Visual Indicator Message
- No Message
