- MFR #
- PM453P PLAN 626
- Zoro #
- G623525253
- UPC #
- 197163387281
- Country of Origin
- Mexico
- Lockset Function ANSI Code
- F20
- Mortise/Cylindrical
- Mortise
- Visual Indicator Location
- Inside/Outside
- Standards
- ANSI/BHMA A156.13-2017, CAN/ULC-S104, ICC A117.1, UL 437 Listed
- Lockset Style
- Playa
- Hand Orientation
- Non-Handed
- Knob/Handle Material
- Zinc
- Includes Core
- Core Included
- Keyway Type
- S123
- ANSI Grade
- 1
- ADA Compliant
- Yes
- Includes
- Dust Box
- Strike Type
- Curved Lip
- Fire Rating
- 3 hr
- Locking/Unlocking Access - Outside
- Keyway
- Key Type
- Keyed Different
- Voltage
- 12/24V DC
- Number of Pins
- 6
- Backset
- 2 3/4 in
- Lockset Type
- Mechanical
- Failure Mode
- Fail Safe or Fail Secure
- Locking/Unlocking Access - Inside
- Thumb Turn
- ANSI/BHMA Finish
- Satin Chromium-Plated
- Latch Bolt/Dead Bolt
- Dead Bolt
- Application
- Commercial Real Estate, Hospitality, Residential, Retail
- Features
Breakaway Spindle Keeps Door Secured in the Event of Vandalism, Two Piece Anti-Friction Tongue in Latch Bolt Reduces Wear, Every Schlage Lock Undergoes Intensive Testing to Determine its ANSI Grade Level Including: Cycle, Resistance, Door Impact, Warped Door and Bolt Strength Tests, Extensive Cylinder Support for Schlage and 7 Non-Schlage Formats, Field Reversible Latch Bolt Allows Handing Change without Opening Case, Lock Status Indication for Sectional Trims (Available on Most Functions) uses Red and White Backgrounds to Ensure Quick Readability for Color Blind Individuals, Patented Everest 29(TM) S123 Keyway Provided Standard which Prohibits Unauthorized Key Duplication, Performance Series Exclusive Levers (Selena and Playa) and D Square Rose are Shared with the Pt Series(TM) Tubular Lock, Security Blocking Hub Prevents Lock Access by Removing Levers, Anti-Saw Pin in Bolt to Prevent Cut-Through
- Key Material
- Nickel Silver
- Performance Grade
- 1
- Item
- Door Lockset
- Cylinder Core Type
- Conventional Core Cylinder
- Visual Indicator Message
- No Message
- Ligature-Resistant
- Not Ligature-Resistant
