Schneider Electric Contact Block, 1NC Slow Break, 16mm ZB6E2B - main

Contact Block, 1NC Slow Break, 16mm

  • Mfr # ZB6E2B

  • Zoro # G0615894

product price: $7.99
/ea

Key Features

Contact Rating
6A @ 250V AC
Size
16 mm
Action
Momentary
Application
Operator
Contact Form
1NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB6E2B
Zoro #
G0615894
UPC #
785901325734
Country of Origin
Spain

Dimensions

Size
16 mm
Manufacturer Warranty Length
18 mo
Connection Size
16 mm

Details

Item
Contact Block
Contact Rating
6A @ 250V AC
Action
Momentary
Application
Operator
Contact Form
1NC
Color
Black
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, UL 508
For Use With
Schneider 16mm Push Buttons
Terminal Connection
Slip On or Faston Connector or Quick Connector
NEMA Contact Rating Designation
B300/R300
Ambient Air Temperature For Operation
-25-70°C
Terminals Description Iso N°1
(1-2)NC
Protective Treatment
TC
[Ui] Rated Insulation Voltage
250 V 3)EN/IEC 60947-1
Operating Travel
1 mm NC changing electrical state) || 3.5 mm total travel)
Positive Opening
with EN/IEC 60947-5-1 appendix K
Device Short Name
ZB6
Electrical Reliability
λ = 10exp(-8) 5 V 1 mA with confidence level of 90 % EN/IEC 60947-5-4
[Ie] Rated Operational Current
3 A 120 V, AC-15, B300 || 1.5 A 240 V, AC-15, B300 || 0.1 A 250 V, DC-13, R300 || 0.22 A 125 V, DC-13, R300
Ip Degree Of Protection
IP20 IEC 60529
Operating Force
2.5 N NC changing electrical state
Ambient Air Temperature For Storage
-40-70°C
Contact Block Type
single
Short-Circuit Protection
6 A cartridge fuse gG
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
[Uimp] Rated Impulse Withstand Voltage
4 kV EN/IEC 60947-1
Vibration Resistance
+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
Product Or Component Type
contact block
Connections - Terminals
Faston connector
Contacts Type And Composition
1 NC
Electrical Durability
1000000 cycles, AC-15 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C || 1000000 cycles, DC-13 230 V 3600 cyc/h 0.5 EN/IEC 60947-5-1 appendix C
Contact Operation
slow-break
Product Certifications
GOST || CSA || UL || CCC
Contacts Material
silver alloy (Ag/Ni)
Mechanical Durability
5000000 cycles
Rated Operational Current
3 A 120 V, AC-15, B300; 1.5 A 240 V, AC-15, B300; 0.1 A 250 V, DC-13, R300; 0.22 A 125 V, DC-13, R300
Terminals Description Iso N°1
(1-2)NC
AC Contact Rating
1.5 A @ 240 V, 3 A @ 120 V
Compatible with Series
ZB6
Switch Action
Momentary
Compatible Operator
Push Button
Includes Mounting Block
No Mounting Block Included
DC Contact Rating
0.1 A @ 250 V, 0.22 A @ 125 V
Terminal Connection Type
Faster Connector

Description

Contact Block, Contact Form 1NC, Contact Rating 6A @ 250V AC, For Use With Schneider 16mm Push Buttons, Action Momentary, 16 mm, Application Operator, NEMA Contact Rating Designation B300/R300, Color Black, Terminal Connection Slip On or Faston Connector or Quick Connector, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C4520, JIS C852, UL 508
