Schneider Electric Contact Block, 1NO + 1 C/O, 30mm 9001KA51 - main

Contact Block, 1NO + 1 C/O, 30mm

  • Mfr # 9001KA51

  • Zoro # G2420074

product price: $143.99
/ea
Free Shipping & Returns

Key Features

Contact Rating
3A @ 240V AC
Size
30 mm
Action
Momentary
Application
Finger Safe Operator
Contact Form
1NO/1NC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KA51
Zoro #
G2420074
UPC #
785901827498
Country of Origin
Japan

Dimensions

Size
30 mm
Manufacturer Warranty Length
18 mo
Connection Size
30 mm

Details

Item
Contact Block
Contact Rating
3A @ 240V AC
Action
Momentary
Application
Finger Safe Operator
Contact Form
1NO/1NC
Color
Black
Safety Rating
Class II Conforming to IEC 61140
NEMA Contact Rating Designation
C300/Q150
Standards
UL 508
Terminal Connection
Screw/Clamp
For Use With
Schneider 9001K Series 30mm Operators
Product Certifications
NEMA || UL 508
Ambient Air Temperature For Operation
-25-70°C
Vibration Resistance
7 gn 2-500 Hz)IEC 60068-2-6
[Icm] Rated Short-Circuit Making Capacity
12 kA 600 V AC-15, 7200 VA || 15 kA 480 V AC-15, 7200 VA || 30 kA 240 V AC-15, 7200 VA || 60 kA 120 V AC-15, 7200 VA || 0.55 kA 125 V DC-13 || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13
Contact Operation
power reed || hermetically sealed
Contacts Type And Composition
1 C/O
[Us] Rated Supply Voltage
240 V
Shape Of Screw Head
cross slotted
Ambient Air Temperature For Storage
-40-70°C
Device Short Name
9001K
[Ith] Conventional Free Air Thermal Current
10 A
Contacts Usage
hermetically sealed contacts
Short-Circuit Protection
10 A cartridge fuse IEC 60947-5-1
Tightening Torque
0.8-0.8 N.m IEC 60947-1
[Uimp] Rated Impulse Withstand Voltage
2.5 kV IEC 60947-1
Electrical Shock Protection Class
class II IEC 61140
Shock Resistance
50 gn IEC 60068-2-27
Positive Opening
without
Rated Breaking Capacity
3 kA 240 V AC-15, 720 VA || 6 kA 120 V AC-15, 720 VA || 1.2 kA 600 V AC-15, 720 VA || 1.5 kA 480 V AC-15, 720 VA || 0.1 kA 600 V DC-13 || 0.27 kA 250 V DC-13 || 0.55 kA 125 V DC-13
Connections - Terminals
screw clamp terminals, 1 x 0.22 to 2 x 2.5 mm² IEC 60947-1, screw-clamp terminals
[Ui] Rated Insulation Voltage
250 V 3)IEC 60947-1
Protective Treatment
TC
Product Or Component Type
contact block
[Ie] Rated Operational Current
3 A 240 V, AC-15, A600-Q600 NEMA || 0.55 A 125 V, DC-13, A600-Q600 NEMA
Rated Short Circuit Making Capacity
12 kA 600 V AC-15, 7200 VA; 15 kA 480 V AC-15, 7200 VA; 30 kA 240 V AC-15, 7200 VA; 60 kA 120 V AC-15, 7200 VA; 0.55 kA 125 V DC-13; 0.1 kA 600 V DC-13; 0.27 kA 250 V DC-13
Conventional Free Air Thermal Current
10 A
Rated Operational Current
3 A 240 V, AC-15, A600-Q600 NEMA; 0.55 A 125 V, DC-13, A600-Q600 NEMA
AC Contact Rating
0.5 A @ 240 V, 1 A @ 120 V
Terminal Connection Type
Screw Clamp Terminals
Compatible Operator
Push Button
DC Contact Rating
0.5 A @ 115 V
Switch Action
Momentary/Power Reed
Compatible with Series
9001K, 9001SK

Description

Contact Block, Contact Form 1NO/1NC, Contact Rating 3A @ 240V AC, For Use With Schneider 9001K Series 30mm Operators, Action Momentary, 30 mm, Application Finger Safe Operator, NEMA Contact Rating Designation C300/Q150, Color Black, Terminal Connection Screw/Clamp, Standards UL 508, Safety Rating Class II Conforming to IEC 61140
