  13. IEC Control Relay, 1NO/1NC, 24VDC, 10A
Schneider Electric IEC Control Relay, 1NO/1NC, 24VDC, 10A CA3SK11BD - main

IEC Control Relay, 1NO/1NC, 24VDC, 10A

  • Mfr # CA3SK11BD

  • Zoro # G0371235

product price: $81.25
/ea
Free Shipping & Returns

Key Features

Item - Relay
IEC Style Control Relay
AC Contact Rating - Relay
10A @ 120/240/480/600V
DC Contact Rating - Relay
2.00A @ 125/250/600V
Number of Pins - Relay
6
Contact Form - Relay
(1) SPST-NC, (1) SPST-NO
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CA3SK11BD
Zoro #
G0371235
UPC #
785901866749
Country of Origin
Czechia

Dimensions

Body Height - Relay
2.28 in
Body Depth - Relay
2.24 in
Overall Height - Relay
2.28 in
Body Width - Relay
1.77 in
Width
27 mm
Height
56 mm
Depth
55.5 mm
Body Height
2.2 in
Overall Height
2.2 in
Body Depth
2.19 in
Body Width
1.06 in

Details

Item - Relay
IEC Style Control Relay
Coil Volts
24V DC
AC Contact Rating - Relay
10A @ 120/240/480/600V
DC Contact Rating - Relay
2.00A @ 125/250/600V
Number of Pins - Relay
6
Contact Form - Relay
(1) SPST-NC, (1) SPST-NO
Mounting - Relay
DIN Rail, Surface
Item
IEC Control Relay
Response Time
10 to 18 msec (Coil Energisation and NC Opening), 4 to 6 msec (Coil De-Energisation and NO Opening), 6 to 8 msec (Coil De-Energisation and NC Closing), 8 to 12 msec (Coil Energisation and NO Closing)
Power Consumption - Relay
3.0 VA
Standards
CCC, CSA Certified, EAC, IEC, REACH, RoHS Compliant, UL Listed
Contact Form
1NO/1NC
Coil Rating
3VA Inrush, 3VA Sealed
Mounting
Din Rail/Panel
Contact Amp Rating (Resistive)
10A
Contact Material
Silver Nickel
Product Certifications
CB Scheme || cULus || EAC || CE || UKCA
Range
TeSys
Utilisation Category
DC-13 || AC-15
Contactor Application
control circuit
[Ui] Rated Insulation Voltage
690 V IEC 60947 || 690 V VDE 0110 group C || 690 V BS 5424 || 690 V UL 508 || 690 V CSA C22.2 No 14
Operating Time
4...6 ms coil de-energisation and NO opening || 8...12 ms coil energisation and NO closing || 6...8 ms coil de-energisation and NC closing || 10...18 ms coil energisation and NC opening
Operating Altitude
6561.68 ft (2000 m) without derating
Ambient Air Temperature For Operation
-20-50°C
Product Name
TeSys CASK
Ambient Air Temperature For Storage
-50-70°C
Control Circuit Voltage Limits
operational 0.85...1.1 Uc 50°C) || drop-out 0.1...0.75 Uc 50°C)
Heat Dissipation
2.2-2.2 W
Hold-In Power Consumption In W
2.2-2.2 W 20°C
Inrush Power In W
2.2-2.2 W 20°C)
Connections - Terminals
screw clamp terminals 1 1.5-6 mm²solid || screw clamp terminals 2 1.5-4 mm²solid || screw clamp terminals 1 0.5-6 mm²flexible without cable end || screw clamp terminals 1 0.35-6 mm²flexible with cable end || screw clamp terminals 2 0.35-1.5 mm²flexible with cable end || screw clamp terminals 2 0.35-2.5 mm²flexible without cable end
Product Or Component Type
control relay
Control Circuit Type
DC standard
[Uc] Control Circuit Voltage
24 V DC
Maximum Operating Rate
1200 cyc/h
Associated Fuse Rating
10 A gL VDE 0660 || 10 A gL IEC 60947
Mounting Support
rail || plate
Mechanical Durability
10 Mcycles
Protective Treatment
TC IEC 60068
Tightening Torque
0.8 N.m screw clamp terminals pozidriv No 1
[Ith] Conventional Free Air Thermal Current
10 A 55°C
[Ue] Rated Operational Voltage
<= 690 V <= 400 Hz
Pole Contact Composition
1 NO + 1 NC
Device Short Name
CA3SK
Ip Degree Of Protection
IP2X
Coil Voltage
24V DC
Weight
0.29 lb
Contact Rating (AC)
10 A @ 120/240/480/600V
Relay Style
IEC
Mounting Style
DIN Rail
Compatible with Series
TeSys SK Mini Control Relays
Minimum Operating Temperature
-4 Degrees F
Number of Pins
6
IP Rating
IP2X
Maximum Operating Temperature
122 Degrees F
Input Voltage
24V DC
Power Consumption
2.2 W
Current Rating
10 A
Contact Rating (DC)
2 A @ 125/250/600V
Electrical Connection
Screw Clamp

Description

IEC Control Relay, Current Rating 10 A, Contact Form 1NO/1NC, Contact Rating (DC) 2 A @ 125/250/600V, Coil Voltage 24V DC, Contact Rating (AC) 10 A @ 120/240/480/600V, Relay Style IEC, Electrical Connection Screw Clamp, Mounting Style DIN Rail, Power Consumption 2.2 W, IP Rating IP2X, Compatible with Series TeSys SK Mini Control Relays, Maximum Operating Temperature 122 Degrees F, Body Depth 2.19 in, Body Height 2.2 in, Body Width 1.06 in, Contact Material Silver Nickel, Input Voltage 24V DC
