Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type LC1G185EHEN - main

IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type

  • Mfr # LC1G185EHEN

  • Zoro # G410190367

product price: $1,014.99
/ea
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G185EHEN
Zoro #
G410190367
UPC #
3606481921840
Country of Origin
China

Dimensions

Overall Height
7.6 in
Overall Width
4.25 in
Overall Depth
7.6 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
3
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
IP Rating
IP20
Series
TeSys Giga
Maximum Voltage Rating
1000V AC
Embedded Surge Suppressor
No
Mechanical Operating Durability
8,000,000
Includes Auxiliary Contacts
Yes
Phase
Single
Contactor Style
IEC
Frequency
50/60 Hz
Minimum Operating Temperature
-13 Degrees F
Mounting Style
Plate
Maximum Operating Temperature
140 Degrees F
Full Load Current - Inductive
185 A
Full Load Current - Resistive
305 A

Description

Schneider Electric’s IEC Magnetic Contactor, TeSys Giga series, is an electrically operated switching device rated for use in applications compliant with IEC standards. It is a 3-pole device with two integrated auxiliary contacts (1NC/1NO) and a coil rated for operation within the specified voltage range (48–130 V AC/DC). The unit features Spring Type terminal connections and plate mounting compatible with standard IEC configurations.

Auxiliary contacts: 2 total (1NC/1NO); Includes Auxiliary Contacts: Yes; Auxiliary Contact Form: 1NC/1NO

  • Coil voltage: 48V-130V AC/DC
  • Poles: 3; Phase: Single; Item: IEC Magnetic Contactor
  • Terminal connection type: Spring Type; Mounting style: Plate
  • Rated for operation up to 1000 V AC as per specifications
  • IP rating: IP20
  • Frequency: 50/60 Hz
  • Embedded surge suppressor: No
  • Mechanical operating durability: tested to withstand up to 8,000,000 mechanical cycles under specified conditions
  • Temperature range: -13°F to 140°F (approximately -25°C to 60°C)
  • Full Load Amps: Inductive 250 A; Resistive 305 A
  • Full Load Current: Inductive 185 A; Resistive 305 A
  • Dimensions: Overall Height 7.6 in; Overall Depth 7.6 in; Overall Width 4.25 in
  • Series: TeSys Giga
  • Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
