IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type

Mfr # LC1G800EHEA
Zoro # G010190361

5,983.99

Free Shipping & Returns

Key Features

Auxiliary Contact Form

1NC/1NO

Coil Voltage

48V-130V AC/DC

Number of Poles

Full Load Amps-Inductive

800 A

Full Load Amps-Resistive

1,050 A

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: LC1G800EHEA
Zoro #: G010190361
UPC #: 3606481922410
Country of Origin: China

Dimensions

Overall Depth: 10.47 in
Overall Width: 8.31 in
Overall Height: 15.3 in

Details

Item: IEC Magnetic Contactor
Auxiliary Contact Form: 1NC/1NO
Coil Voltage: 48V-130V AC/DC
Number of Poles: 3
Full Load Amps-Inductive: 800 A
Full Load Amps-Resistive: 1,050 A
Terminal Connection Type: Spring Type
Number of Auxillary Contacts: 2
Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Series: TeSys Giga
IP Rating: IP20
Maximum Operating Temperature: 140 Degrees F
Frequency: 50/60 Hz
Maximum Voltage Rating: 1000V AC
Mounting Style: Plate
Phase: Single
Embedded Surge Suppressor: No
Mechanical Operating Durability: 5,000,000
Minimum Operating Temperature: -13 Degrees F
Contactor Style: IEC
Includes Auxiliary Contacts: Yes
Full Load Current - Resistive: 1,050 A
Full Load Current - Inductive: 800 A

Description

Key features

Type/config: Rated for operation within the specified configurations.

Coil voltage: Within specified voltage ranges; compatible within these parameters.

Auxiliary contacts: Yes (2 total; 1NC/1NO)

Embedded surge suppressor: No

Frequency: Supports standard frequency ranges; not guaranteed for all conditions outside these specifications.

Maximum voltage rating: Rated for operation up to this voltage level within specified conditions.

Full-load ratings: Based on standardized testing; actual performance may vary depending on application conditions.

Full-load current: Based on rated values under test conditions; actual current capacity may differ based on installation specifics.

IP rating: Meets the specified ingress protection level when installed properly but does not imply suitability for harsh environments without additional measures.

Mounting/terminals: Plate mounting; Spring Type terminal connections

Poles/phase: Configured as indicated; verify suitability for intended electrical system phases before use.

Series: TeSys Giga

Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1

Mechanical durability: Approximate cycles based on testing standards but actual lifespan depends on operating conditions.

Operating temperature: - Not indicative of safety or performance outside this temperature range unless tested accordingly.

Overall dimensions: Provided for reference only.
