  13. IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type
Schneider Electric IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type LC1G5004EHEA - main

IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type

  • Mfr # LC1G5004EHEA

  • Zoro # G510354539

product price: $4,291.99
/ea
Sold in multiples of 4 for $17,167.96
Free Shipping & Returns

Key Features

Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LC1G5004EHEA
Zoro #
G510354539
UPC #
3606481922694
Country of Origin
China

Dimensions

Overall Width
7.28 in
Overall Depth
4.8 in
Overall Height
11.42 in

Details

Item
IEC Magnetic Contactor
Auxiliary Contact Form
1NC/1NO
Coil Voltage
48V-130V AC/DC
Number of Poles
4
Terminal Connection Type
Spring Type
Number of Auxillary Contacts
2
Standards
CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
IP Rating
IP20
Series
TeSys Giga
Contactor Style
IEC
Maximum Operating Temperature
140 Degrees F
Minimum Operating Temperature
-13 Degrees F
Mounting Style
Plate
Includes Auxiliary Contacts
Yes
Maximum Voltage Rating
1000V AC
Phase
Single
Mechanical Operating Durability
8,000,000
Frequency
50/60 Hz
Embedded Surge Suppressor
No
Full Load Current - Inductive
500 A
Full Load Current - Resistive
700 A

Description

The IEC Magnetic Contactor (TeSys Giga) is a 4-pole, electrically operated switching device used to control power circuits. Rated for operation within the specified voltage ranges (48V-130V AC/DC), auxiliary contacts configured as 1NC/1NO (2 total), and spring-type terminals mounted on a plate. It is a single-phase device, rated for operation within the specified voltage limits (1000V AC), conforming to IP20 ingress protection standards, and listed under the TeSys Giga series designation. The unit is rated for operation at frequencies of 50/60 Hz, (-13°F to 140°F) ambient temperatures, and is designed to withstand a specified number of operational cycles. It does not contain an integrated surge suppression device.

Item: IEC Magnetic Contactor (TeSys Giga), 4 poles, plate mounting

  • Coil Voltage: 48V-130V AC/DC
  • Auxiliary Contacts: 2 total (Form 1NC/1NO)
  • Embedded Surge Suppressor: No
  • Frequency: 50/60 Hz
  • Maximum Voltage Rating: Rated for operation within the specified voltage limits (1000V AC)
  • Full Load Amps - Inductive: 630 A; Full Load Amps - Resistive: 700 A
  • Full Load Current - Inductive: 500 A; Full Load Current - Resistive: 700 A
  • IP Rating: Conforms to IP20 ingress protection standards
  • Includes Auxiliary Contacts: Yes
  • Number of Auxillary Contacts: 2
  • Phase: Single
  • Series: TeSys Giga
  • Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • Mounting Style: Plate
  • Terminal Connection Type: Spring Type
  • Maximum Operating Temperature: 140 Degrees F; Minimum Operating Temperature: -13 Degrees F
  • Overall Dimensions: Depth 4.8 in, Height 11.42 in, Width 7.28 in
