Item
Non-Illuminated Push Button
Push Button Style
Extended
Operator Illumination
Non-Illuminated
Standards
UL 508, IEC 60947-1, JIS C8201-5-1, IEC 60947-5-4, IEC 60947-5-1, CSA C22.2 No 14, IEC 60947-5-5, JIS C8201-1
Type of Operator
spring return
Bezel Material
chromium plated metal
Short-Circuit Protection
10 A cartridge fuse gG IEC 60947-5-1
Light Source
incandescent
[Ith] Conventional Free Air Thermal Current
10 A IEC 60947-5-1
Terminals Description Iso N°1
(21-22)NC, (13-14)NO
Contacts Material
silver alloy (Ag/Ni)
Mechanical Durability
10000000 cycles
Operator Profile
white flush
Vibration Resistance
5 gn 2-500 Hz)IEC 60068-2-6
Shape of Signaling Unit Head
round
Resistance To High Pressure Washer
7000000 Pa 55°C 0.1 m
Product or Component Type
illuminated push-button
Electrical Reliability
λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4, λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4
Ambient Air Temperature For Storage
-40-70°C
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Ambient Air Temperature For Operation
-40-55°C
Tightening Torque
0.8-1.2 N.m IEC 60947-1
Fixing Collar Material
zamak
Contacts Type And Composition
1 NO + 1 NC
Contact Operation
slow-break
Electrical Shock Protection Class
class I IEC 60536
Operating Travel
1.5 mm NC changing electrical state), 2.6 mm NO changing electrical state), 4.3 mm total travel)
Range of Product
Harmony XB4
Light Block Supply
via integral transformer 1.2 VA 6 V
Ip Degree of Protection
IP66 IEC 60529, IP67, IP69, IP69K
[Ie] Rated Operational Current
3 A 240 V, AC-15, A600 IEC 60947-5-1, 6 A 120 V, AC-15, A600 IEC 60947-5-1, 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1, 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1, 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1, 1.2 A 600 V, AC-15, A600 IEC 60947-5-1
Operating Force
3.5 N NC changing electrical state, 3.8 N
Positive Opening
with IEC 60947-5-1 appendix K
[Ui] Rated Insulation Voltage
600 V 3)IEC 60947-1
Shape of Screw Head
cross Philips no 1, cross pozidriv No 1, slotted flat Ø 4 mm, slotted flat Ø 5.5 mm
[Us] Rated Supply Voltage
110...120 V AC 50/60 Hz
Ik Degree of Protection
IK06 conforming to IEC 50102
Electrical Durability
1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.2 A 110 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C, 1000000 cycles, DC-13, 0.5 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
Nema Degree of Protection
NEMA 13, NEMA 4X
Operator Additional Information
with plain lens
Device Presentation
complete product
[Uimp] Rated Impulse Withstand Voltage
6 kV IEC 60947-1
Contacts Usage
standard contacts
Connections - Terminals
screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1, screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1
Product Or Component Type
illuminated push-button
Ip Degree Of Protection
IP66 IEC 60529 || IP67 || IP69 || IP69K
Shape Of Signaling Unit Head
round
Ik Degree Of Protection
IK06 IEC 50102
Product Certifications
GL || CSA || LROS (Lloyds register of shipping) || DNV || UL Listed || BV
Shape Of Screw Head
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Nema Degree Of Protection
NEMA 13 || NEMA 4X
Type Of Operator
spring return
