  8. Illuminated Push Button Operator, 30 mm, Red

This item is Discontinued.

Schneider Electric Illuminated Push Button Operator, 30 mm, Red 9001KR9P38LR

Illuminated Push Button Operator, 30 mm, Red (Discontinued)

  • Mfr # 9001KR9P38LR
  • Zoro # G6342497
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
9001KR9P38LR
Zoro #
G6342497
UPC #
785901318521
Country of Origin
Mexico

Dimensions

Panel Cutout Diameter
30 mm
Mushroom Head Diameter
40 mm
Size
30 mm
Mounting Diameter
30 mm
Manufacturer Warranty Length
18 mo
Overall Height
1.62 in
Overall Width
2.13 in

Details

Item
Mushroom Head Push Button
Push Button Style
Mushroom Head
Action
Maintained
Maintained Action Release
Push/Pull
Operator Illumination
Illuminated
Head Material
Metal
Terminal Connection
Screw Clamp
Standards
REACH Free of SVHC, RoHS
Replacement Lamp
4VCW4
Basic Material
Metal
IP Rating
IP66
Lamp Module Voltage
120V AC
Bezel
Metal
Lamp Type
LED
Lamp Voltage
120V AC
Type of Operator
57mm Mushroom Head
Lamp Module Type
Full Voltage
Color
Red
NEMA Rating
13, 3, 3R, 6
Bezel Material
Metal
Number of Operators
1
Series
9001K
Light Source Colour
red
[Us] Rated Supply Voltage
120 V
Contacts Type And Composition
without contact block
Shape Of Signaling Unit Head
round
Device Short Name
9001K
Cap/Operator Or Lens Colour
without mushroom
Operator Position Information
2 positions
Product Or Component Type
head for illuminated push-button
Operator Profile
flush
Lamp Voltage - Maximum
120 V AC/DC
Number of Indicator Lights
1
Operator Material
Metal
Hazardous Location Specification
Not Rated
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4
Product Type
Push Button Operators

Description

Mushroom Head Push Button, 30 mm, Maintained, Type of Operator 57mm Mushroom Head, Basic Material Metal, Head Material Metal, Bezel Material Metal, Color Red, NEMA Rating 13, 3, 3R, 6, IP Rating IP66, Legend Not Applicable, Standards REACH Free of SVHC, RoHS
