Schneider Electric Lamp Module, 22mm, 250V ZB5AV6 - main

Lamp Module, 22mm, 250V

  • Mfr # ZB5AV6

  • Zoro # G0461596

product price: $39.39
/ea

Key Features

Size
22 mm
Lamp Module Voltage
240V AC
IP Rating
Not Rated
Material of Construction
Plastic
NEMA Rating
1, 12, 13, 2, 3, 4, 4X
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB5AV6
Zoro #
G0461596
UPC #
785901908289
Country of Origin
France

Dimensions

Size
22 mm
Cad Overall Depth
32 mm
Cad Overall Height
42 mm
Cad Overall Width
30 mm
Overall Height
1.65 in
Manufacturer Warranty Length
18 mo
Compatible Panel Cutout Diameter
22 mm
Overall Width
1.18 in
Overall Depth
1.26 in

Details

Item
Lamp Module
Lamp Module Voltage
240V AC
IP Rating
Not Rated
Material of Construction
Plastic
NEMA Rating
1, 12, 13, 2, 3, 4, 4X
Lamp Module Type
Full Voltage
For Use With
XB4/5 Illuminated Operators and Pilot Lights
Lamp Type
Incandescent
Terminal Connection
Screw Clamp
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
Lamp Voltage
250V AC
Body Material
Plastic
Fixing Collar Material
plastic
Vibration Resistance
5 gn 2-500 Hz)IEC 60068-2-6
Light Block Supply
direct <2.4 W
Bulb Base
BA 9s
Shape Of Screw Head
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Protective Treatment
TH
Product Or Component Type
complete body/light block assembly
Ambient Air Temperature For Operation
-40-70°C
[Ui] Rated Insulation Voltage
600 V 3)EN 60947-1
Tightening Torque
0.8-1.2 N.m EN 60947-1
Device Presentation
basic sub-assemblies
Ambient Air Temperature For Storage
-40-70°C
Light Source
bulb not included
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Signalling Type
steady
[Uimp] Rated Impulse Withstand Voltage
6 kV EN 60947-1
Product Certifications
UL Listed || CSA || DNV || BV || GL || LROS (Lloyds register of shipping)
Device Short Name
ZB5
Electrical Shock Protection Class
class II IEC 60536
Connections - Terminals
screw clamp terminals, <= 2 x 1.5 mm² with cable end EN 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end EN 60947-1
[Us] Rated Supply Voltage
<= 250 V
Terminals Description Iso N°1
(X1-X2)PL
Rated Supply Voltage
Less than or Equal to 250 V
Rated Insulation Voltage
600 V 3)IEC 60947-1
Rated Impulse Withstand Voltage
6 kV IEC 60947-1
Terminals Description Iso N°1
(X1-X2)PL
NEMA Enclosure Rating
No Enclosure
Compatible with Series
XB5
Terminal Connection Type
Screw Clamp Terminals
Compatible with Brand
Schneider
Voltage Rating - Maximum
250 V AC
Compatible Operator
Selector Switch
Includes Bulb
No Bulb Included

Description

Lamp Module, Lamp Module Voltage 240V AC, Not Applicable, Lamp Type Incandescent, Lamp Voltage 250V AC, Terminal Connection Screw Clamp, 22 mm, Lamp Module Type Full Voltage, Plastic Material of Construction, NEMA Rating 1, 12, 13, 2, 3, 4, 4X, IP Rating Not Rated, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508, For Use With XB4/5 Illuminated Operators and Pilot Lights
