  15. Light Block Assembly, 22 mm, White
Schneider Electric Light Block Assembly, 22 mm, White ZB5AVBG1 - main

Light Block Assembly, 22 mm, White

  • Mfr # ZB5AVBG1

  • Zoro # G3547294

product price: $45.29
/ea

Key Features

Panel Cutout Diameter
22 mm
Head Color
White
Head Material
Plastic
Terminal Connection
Screw Clamp
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ZB5AVBG1
Zoro #
G3547294
UPC #
785901613374
Country of Origin
France

Dimensions

Panel Cutout Diameter
22 mm
Size
22 mm
Cad Overall Height
42 mm
Cad Overall Depth
32 mm
Cad Overall Width
30 mm
Manufacturer Warranty Length
18 mo
Compatible Panel Cutout Diameter
22 mm
Overall Width
1.18 in
Overall Height
1.65 in
Overall Depth
1.26 in

Details

Item
Push Button with Contact Block
Head Color
White
Head Material
Plastic
Terminal Connection
Screw Clamp
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
Lamp Type
LED
Lamp Module Type
Full Voltage
Lamp Module Voltage
24 to 120V AC/DC
Color
White
Material of Construction
Plastic
IP Rating
Not Rated
Body Material
Plastic
Lamp Voltage
24 to 120V AC/DC
Vibration Resistance
5 gn 2-500 Hz)IEC 60068-2-6
Surge Withstand
1 kV IEC 61000-4-5
Ambient Air Temperature For Storage
-40-70°C
Bulb Base
integral LED
Product Or Component Type
complete body/light block assembly
Resistance To Electromagnetic Fields
10 V/m IEC 61000-4-3
[Uimp] Rated Impulse Withstand Voltage
6 kV EN 60947-1
[Ui] Rated Insulation Voltage
600 V 3)EN 60947-1
Device Presentation
basic sub-assemblies
Signalling Type
steady
Ambient Air Temperature For Operation
-40-70°C
Resistance To Electrostatic Discharge
6 kV on contact (on metal parts) IEC 61000-2-6 || 8 kV in free air (in insulating parts) IEC 61000-2-6
Supply Voltage Limits
19.2-132 V DC || 21.6-132 V AC
Connections - Terminals
screw clamp terminals, <= 2 x 1.5 mm² with cable end EN 60947-1 || screw clamp terminals, >= 1 x 0.22 mm² without cable end EN 60947-1
[Us] Rated Supply Voltage
24 to 120 V AC/DC 50/60 Hz
Tightening Torque
0.8-1.2 N.m EN 60947-1
Resistance To Fast Transients
2 kV IEC 61000-4-4
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Light Source
universal LED
Electromagnetic Emission
class B IEC 55011
Protective Treatment
TH
Electrical Shock Protection Class
class II IEC 60536
Fixing Collar Material
plastic
Shape Of Screw Head
cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm
Device Short Name
ZB5
Light Source Colour
white
Terminals Description Iso N°1
(X1-X2)PL
Product Certifications
DNV || BV || CSA || UL Listed || LROS (Lloyds register of shipping) || GL
Terminals Description Iso N°1
(X1-X2)PL
Voltage Rating - Maximum
120 V AC
NEMA Enclosure Rating
No Enclosure
Compatible Operator
Selector Switch
Terminal Connection Type
Screw Clamp Terminals
Includes Bulb
Bulb Included
Compatible with Series
XB5
Compatible with Brand
Schneider

Description

Light Block, Lamp Module Voltage 24 to 120V AC/DC, White, Lamp Type LED, Lamp Voltage 24 to 120V AC/DC, Terminal Connection Screw Clamp, 22 mm, Lamp Module Type Full Voltage, Plastic Material of Construction, IP Rating Not Rated, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
