  13. Manual Motor Starter, 3 P, Push Button, 14 A
Schneider Electric Manual Motor Starter, 3 P, Push Button, 14 A GV2ME163 - main

Manual Motor Starter, 3 P, Push Button, 14 A

  • Mfr # GV2ME163

  • Zoro # G0851840

product price: $259.99
/ea
Free Shipping & Returns

Key Features

Number of Poles
3
Operator
Push Button
Current AC
14 A
Series
TeSys Deca
Standards
EN/IEC 60947-2 || EN/IEC 60947-4-1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GV2ME163
Zoro #
G0851840
UPC #
785901212195
Country of Origin
France

Dimensions

Overall Depth
78.5 mm
Overall Width
45 mm
Overall Height
101 mm

Details

Item
Manual Motor Starter
Number of Poles
3
Operator
Push Button
Current AC
14 A
Series
TeSys Deca
Standards
EN/IEC 60947-2 || EN/IEC 60947-4-1
Color
dark grey
Fixing Mode
35 mm symmetrical DIN rail clipped || panel screwed with adaptor plate)
Device Application
motor protection
Thermal Protection Adjustment Range
9-14 A IEC 60947-4-1
Product Name
TeSys GV2 || TeSys Deca
Mechanical Robustness
shocks 30 Gn for 11 ms || vibrations 5 Gn, 5 to 150 Hz
Range
TeSys Deca
Phase Failure Sensitivity
yes IEC 60947-4-1
Trip Unit Technology
thermal-magnetic
Operating Altitude
6561.68 ft (2000 m)
Fire Resistance
960°C IEC 60695-2-11
Network Type
AC
Device Short Name
GV2ME
[Uimp] Rated Impulse Withstand Voltage
6 kV IEC 60947-2
Motor Power Kw
5.5-5.5 kW 400/415 V AC 50/60 Hz || 7.5-7.5 kW 500 V AC 50/60 Hz
Utilisation Category
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Ik Degree Of Protection
IK04
Suitability For Isolation
yes IEC 60947-1§ 7-1-6
Power Dissipation Per Pole
2.5 W
Ambient Air Temperature For Storage
-40-80°C
Rated Duty
continuous IEC 60947-4-1
Climatic Withstand
IACS E10
Magnetic Tripping Current
170-170 A
Maximum Voltage Rating
690V AC
Mechanical Operating Durability
100,000
Maximum Operating Temperature
140 Degrees F
Electrical Operating Durability
100,000
Minimum Operating Temperature
-4 Degrees F
Rated Service Short-Circuit Breaking Capacity
100 % 230/240 V AC 50/60 Hz IEC 60947-2 || 50 % 400/415 V AC 50/60 Hz IEC 60947-2 || 50 % 440 V AC 50/60 Hz IEC 60947-2 || 75 % 500 V AC 50/60 Hz IEC 60947-2 || 75 % 690 V AC 50/60 Hz IEC 60947-2
IP Rating
IP20

Description

Manual Starter 600Vac 14Amp Iec
