Schneider Electric Manual Motor Starter, Not Applicable, 3 P, 3 Phase, Push Button, 0.40 A GV2ME03 - main

Manual Motor Starter, Not Applicable, 3 P, 3 Phase, Push Button, 0.40 A

  • Mfr # GV2ME03

  • Zoro # G0551713

product price:  $198.99
/ea
Free Shipping & Returns

Key Features

Number of Poles
3
Operator
Push Button
Phase
3
Current AC
0.40 A
Series
TeSys Deca
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
GV2ME03
Zoro #
G0551713
UPC #
785901211907
Country of Origin
Thailand

Dimensions

Overall Depth
3.09 in
Overall Width
1.77 in
Overall Height
3.5 in

Details

Item
Manual Motor Starter
Number of Poles
3
Operator
Push Button
Phase
3
Current AC
0.40 A
Series
TeSys Deca
Standards
ATEX Compliant, BV, CCC, CSA, DNV-GL, EAC, EN/IEC 60947-2, EN/IEC 60947-4, LROS, RINA, UKCA, UL Listed
Pilot Light
Yes
Description/Special Features
Screw Clamp Terminals, Single Unit
Phase Loss Sensitivity
Yes
Fire Resistance
960°C IEC 60695-2-11
Mechanical Robustness
shocks 30 Gn for 11 ms || vibrations 5 Gn, 5...150 Hz
Suitability For Isolation
yes IEC 60947-1§ 7-1-6
Network Type
AC
Tightening Torque
1.7 N.m screw clamp terminal
Ambient Air Temperature For Storage
-40-80°C
Thermal Protection Adjustment Range
0.25-0.4 A IEC 60947-4-1
Utilisation Category
category A IEC 60947-2 || AC-3 IEC 60947-4-1
Product Name
TeSys GV2 || TeSys Deca
[Uimp] Rated Impulse Withstand Voltage
6 kV IEC 60947-2
Magnetic Tripping Current
5-5 A
Motor Power Kw
0.09-0.09 kW 400/415 V AC 50/60 Hz
Color
dark grey
Phase Failure Sensitivity
yes IEC 60947-4-1
Power Dissipation Per Pole
2.5 W
Trip Unit Technology
thermal-magnetic
Ik Degree Of Protection
IK04
Device Application
motor protection
Operating Altitude
6561.68 ft (2000 m)
Fixing Mode
35 mm symmetrical DIN rail clipped || panel screwed with adaptor plate)
Device Short Name
GV2ME
Climatic Withstand
IACS E10
Rated Duty
continuous IEC 60947-4-1
Range
TeSys Deca
Overload Protection Type
Thermal
Includes Pilot Light
No
Minimum Overload Relay Current Setting
0.25 A
Starter Style
IEC
Maximum Operating Temperature
140 Degrees F
Frequency
50/60 Hz
Mechanical Operating Durability
100,000
Electrical Operating Durability
100,000
Minimum Operating Temperature
-4 Degrees F
IP Rating
IP20
NEMA Enclosure Rating
No Enclosure
Resistance Properties
Fire Resistant
Terminal Connection Type
Screw Clamp Terminals
Maximum Voltage Rating
690V AC
Rated Service Short-Circuit Breaking Capacity
100% 230/240 V AC 50/60 Hz IEC 60947-2; 100% 400/415 V AC 50/60 Hz IEC 60947-2; 100% 440 V AC 50/60 Hz IEC 60947-2; 100% 500 V AC 50/60 Hz IEC 60947-2; 100% 690 V AC 50/60 Hz IEC 60947-2

Description

Manual Motor Starter, NEMA Size Not Applicable, Maximum Voltage Rating 690V AC, Number of Poles 3, Operator Push Button, Phase Three, Current AC 0.4 A, Series TeSys Deca, Maximum Overload Relay Current Setting 0.4 A, Minimum Overload Relay Current Setting 0.25 A, NEMA Enclosure Rating No Enclosure, Overload Protection Type Thermal, Starter Style IEC, Terminal Connection Type Screw Clamp Terminals, IP Rating IP20, Resistance Properties Fire Resistant, Frequency 50/60 Hz, Overall Depth 3.09 in
