PCB, Slim Plug-In Relay, Square, 6 A, 5 Pins, Plug-in

  • Mfr # RSL1AB4BD

  • Zoro # G3651837

CAD Available

product price: $10.39
/ea

Key Features

CAD Drawing
Mounting Style
PCB
Electrical Connection
Plug-in
Base Shape
Square
Number of Pins
5
Coil Voltage
24V DC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
RSL1AB4BD
Zoro #
G3651837
UPC #
785901695226
Country of Origin
China

Dimensions

Overall Height - Relay
0.73 in
Body Height
1.1 in
Overall Depth
0.74 in
Body Width
0.19 in
Body Depth
0.72 in

Description

"This Harmony RSL slim interfacing plug-in relay has a coil control voltage of 24V DC and has 1 changeover contact SPDT (single pole double throw) with a rating of 6A." "It has large choice of number of contacts for high rated current use." "It helps to reduce the size of enclosures and increases machine reliability, you can mount nearly everywhere." "One of the slimiest interface relay on the market, with 6mm width, it can be installed nearly anywhere." "Easy installation and withdrawal the relay from its socket." "It is compatible with high breaking capacity or low-level current application requirements." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)." "[delete]" "Status display with LED, clearly signal both in the day and night."
