Pendant Contact, F/XAC, XACA, XACA9

Pendant Contact

Black

Mfr. No. XAC, XACA, XACA9 Series

EN/IEC 60947-5-1 || CSA C22.2 No 14 || UL 508

Spring Return, 1 Speed, 2NO/1NC Contacts

2NO/1NC Contacts, Front Mounting

XENG

XACA9...head || XACA

contact block

single speed

screw clamp terminals, 1 x 0.5...1 x 2.5 mm² without cable end || screw clamp terminals, 1 x 0.5...2 x 1.5 mm² with cable end

-25-70°C

front mounting

(21-22)NC || (13-14)NO || (33-34)NO

15 gn 10-500 Hz)IEC 60068-2-6

control circuit

600 V 3)IEC 60947-1

18 N

1 NC + 2 NO

single

10 A fuse protection cartridge gG

slow-break || simultaneous

spring return

A600 AC-15, Ue = 240 V, Ie = 3 A IEC 60947-5-1 appendix A || A600 AC-15, Ue = 600 V, Ie = 1.2 A IEC 60947-5-1 appendix A || Q600 DC-13, Ue = 250 V, Ie = 0.27 A IEC 60947-5-1 appendix A || Q600 DC-13, Ue = 600 V, Ie = 0.1 A IEC 60947-5-1 appendix A

25 MOhm

6 kV IEC 60947-1

100 gn IEC 60068-2-27

1000000 cycles

class II IEC 61140

10A

-40-70°C

40 W DC-13 1000000 cycles 60 cyc/mn 120 V 0.5 inductive IEC 60947-5-1 appendix C || 48 W DC-13 1000000 cycles 60 cyc/mn 48 V 0.5 inductive IEC 60947-5-1 appendix C || 65 W DC-13 1000000 cycles 60 cyc/mn 24 V 0.5 inductive IEC 60947-5-1 appendix C

(21-22)NC || (13-14)NO || (33-34)NO

XAC

Pendant Control Stations

Contact Block
