  15. Pilot light, Harmony XVL, plastic, yellow, 12mm, covered LED, 12V DC
Schneider Electric Pilot light, Harmony XVL, plastic, yellow, 12mm, covered LED, 12V DC XVLA325 - main

Pilot light, Harmony XVL, plastic, yellow, 12mm, covered LED, 12V DC

  • Mfr # XVLA325

  • Zoro # G0858177

product price: $41.15
/ea

Key Features

Voltage
12V
Color
Yellow
Lamp Type
Covered LED
Terminal Connection
Threaded connector
Contact Form
(X1-X2)PL
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XVLA325
Zoro #
G0858177
UPC #
785901171300
Country of Origin
Spain

Dimensions

Width
16 mm
Height
16 mm
Length
51 mm
Depth
51 mm
Mounting Diameter
12 mm

Details

Item
Pilot Light 12V 12Mm +Options
Voltage
12V
Color
Yellow
Lamp Type
Covered LED
Terminal Connection
Threaded connector
Contact Form
(X1-X2)PL
Average Life
100000 hr
Standards
CSA, UL
IP Rating
IP65/IP40
[Ui] Rated Insulation Voltage
50 V IEC 60947-1
Ambient Air Temperature For Storage
-40-70°C
[Us] Rated Supply Voltage
12 V
Supply Circuit Type
DC
Light Source
covered LED
Terminals Description Iso N°1
(X1-X2)PL
Protective Treatment
TC
Ambient Air Temperature For Operation
-25-70°C
Nominal Voltage Limit
0.8...1.1 Un
Light Block Colour
yellow
Bulb Lifespan
100000 h
Component Name
XVL
Range of Product
Harmony XVL
Product or Component Type
LED pilot light with integral lens cap
Current Consumption
18 mA
Ip Degree of Protection
IP65 IEC 60529 with seal XVLZ912), IP65 NF C 20-010 with seal XVLZ912), IP40 IEC 60529, IP40 NF C 20-010
Protection Type
integral ballast resistor, built-in by diode
Connections - Terminals
threaded connector 1 x 0.2...1 x 1.5 mm²
Overvoltage Category
class 3 IEC 60536, class 3 NF C 20-030
Rated Insulation Voltage
50 V IEC 60947-1
Rated Supply Voltage
12 V
IP Degree Of Protection
IP65 IEC 60529 with seal XVLZ912; IP65 NF C 20-010 with seal XVLZ912; IP40 IEC 60529; IP40 NF C 20-010
Product Or Component Type
LED pilot light with integral lens cap

Description

Pilot Light 12V 12Mm +Options
