  13. Plug in relay, Harmony Solid State Relays, 2A, zero voltage switching, input 15 to 30V DC, output 24 to 280V AC
Schneider Electric Plug in relay, Harmony Solid State Relays, 2A, zero voltage switching, input 15 to 30V DC, output 24 to 280V AC SSL1A12BD - main

Plug in relay, Harmony Solid State Relays, 2A, zero voltage switching, input 15 to 30V DC, output 24 to 280V AC

  • Mfr # SSL1A12BD

  • Zoro # G7331435

product price: $20.29
/ea
Sold in multiples of 12 for $243.48

Key Features

Response Time
0.5 cycle (turn-on) || 0.5 cycle (turn-off)
Depth
15 mm
Height
28 mm
Width
5 mm
Dielectric Strength
2500 V for input/output
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SSL1A12BD
Zoro #
G7331435
UPC #
-
Country of Origin
Mexico

Dimensions

Depth
15 mm
Height
28 mm
Width
5 mm

Details

Item
SsrSlim,1 Chann 2A@24-280VAC Zero,15-30
Response Time
0.5 cycle (turn-on) || 0.5 cycle (turn-off)
Dielectric Strength
2500 V for input/output
Maximum Switching Voltage
10 V DC turn-off
Dv/Dt
500 V/µs off-state at maximum voltage
Overvoltage Category
III
Absolute Maximum Voltage
600 V AC
Input Impedance
3500 Ohm
Surge Current
120 A 16.6 ms || 115 A 20 ms
Pollution Degree
2
Mounting Support
socket
Output Voltage
24...280 V AC
Marking
CE
Flame Retardance
V0 conforming to UL 94
Maximum Voltage Drop
<1.1 V on-state
Maximum I²T For Fusing
66 A².s for 10 ms at 50 Hz || 60 A².s for 8.3 ms at 60 Hz
Minimum Switching Voltage
15 V DC turn-on
Product Certifications
UL || CSA
Line Rated Current
2A
Ambient Air Temperature For Storage
-20-85°C
Capacitance Unbalance
1.5 pF input/output
Phase
1 phase
Product Or Component Type
solid state relay up to 10 A
Maximum Leakage Current
4 mA off-state
Output Switching Mode
DC switching
Device Short Name
SSL
Solid State Output Type
zero voltage switching || SCR output
Ambient Air Temperature For Operation
-20-80°C
Input Current Limits
6-6 mA
[Uc] Control Circuit Voltage
15...30 V DC
Load Current
0.07-2 A
Range of Product
Harmony Solid State Relays

Description

This Harmony SSL slim interfacing solid state plug-in relay is rated 2A, is controlled with a 3V to 12V DC input, has a rated load voltage of 24V to 280V AC with zero voltage switching, ideal for resistive loads. It is 6mm width, including socket, to save space in your control cabinets. It is also silent and reliable thanks to the absence of moving contacts. It is shock, vibration and pollution resistant thanks to its IP67, it makes it ideal for harsh industrial environments.
