Schneider Electric Push Button Operator, Extended, Momentary Action, Not Applicable Release, Non-Illuminated, Red 9001KR2RH5 - main

Push Button Operator, Extended, Momentary Action, Not Applicable Release, Non-Illuminated, Red

  • Mfr # 9001KR2RH5

  • Zoro # G2201507

product price: $60.89
/ea

Key Features

Push Button Style
Extended
Action
Momentary
Operator Illumination
Non-Illuminated
Panel Cutout Diameter
30 mm
Head Color
Red
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KR2RH5
Zoro #
G2201507
UPC #
785901033684
Country of Origin
Mexico

Dimensions

Panel Cutout Diameter
30 mm
Size
30 mm
Mounting Diameter
30 mm
Manufacturer Warranty Length
18 mo

Details

Item
Push Button Operator
Push Button Style
Extended
Action
Momentary
Operator Illumination
Non-Illuminated
Head Color
Red
Head Material
Metal
Terminal Connection
Screw Clamp
Standards
CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE
NEMA Rating
1, 12, 13, 2, 3, 3R, 4, 6
Number of Operators
1
Type of Operator
Extended Button
Contact Form
1NO
Material
metal
Bezel
Chrome Plated Zinc Die Cast
IP Rating
IP66
NEMA Contact Rating Designation
A600/Q600
Basic Material
Metal
Contact Rating
10A @ 600V AC
Color
Red
Bezel Material
Metal
DC Contact Rating
0.1 A @ 600 V, 0.27 A @ 250 V, 0.55 A @ 125 V
AC Contact Rating
1.2 A @ 600 V, 1.5 A @ 480 V, 3 A @ 240 V, 6 A @ 120 V
Series
9001K
Product Type
Push Button Operators
Cap/Operator Or Lens Colour
red
Product Or Component Type
push-button
Device Presentation
complete product
Nema Degree Of Protection
NEMA 1/2/3/3R/4/6/12/13
Operator Profile
recessed, red recessed
Contact Operation
standard
Light Source
without
[Ie] Rated Operational Current
10 A, AC-15 || 10 A, DC-13
Device Short Name
K
Connections - Terminals
screw clamp terminals
Operating Position
any position
Product Certifications
CSA LR 25490 class 3211 03 || UL listed file E42259 CCN NKCR || NEMA || CE
Operator Additional Information
metal guard
Contacts Type And Composition
1 NO
Light Block Supply
without supply
Rated Operational Current
10 A, AC-15; 10 A, DC-13
Operating Temperature - Maximum
140 Degrees F
Operating Temperature - Minimum
-22 Degrees F
Operator Voltage Rating - Maximum
600 V AC
Hazardous Location Specification
Class I, Div 2, Group A, B, C, D, Class II, Div 2, Group E, F, G, Class III, Div 1 and 2
Number of Indicator Lights
0
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4, 6
Resistance Properties
Corrosion Resistant, Dust Resistant, Impact Resistant, Vibration Resistant, Watertight
Operator Material
Metal

Description

Extended Push Button Operator, 30 mm, Momentary Action, Extended Button Type of Operator, Head Material Metal, Contact Form 1NO, Bezel Chrome Plated Zinc Die Cast, Color Red, Contact Rating 10A @ 600V AC, NEMA Contact Rating Designation A600/Q600, Number of Operators 1, NEMA Rating 1, 12, 13, 2, 3, 3R, 4, 6, IP Rating IP66, Legend Not Applicable, Standards CE, CSA LR25490 Class 3211 03, REACH, RoHS, UL E42259 CCN NKCR, WEEE, Terminal Connection Screw Clamp, Material Metal
