Shop SCHNEIDER ELECTRIC

Single contact block, Harmony XB4, silver alloy, faston connector, 1NO

  • Mfr # ZBE1013
  • Zoro # G7655008
product price:
$
12.35
/ea

Key Features

Standards
IEC 60947-5-4, JIS C8201-5-1, UL 508, CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, JIS C8201-1
[Ui] Rated Insulation Voltage
250 V 3)IEC 60947-1
Protective Treatment
TH
Ambient Air Temperature For Storage
-40-70°C
Operating Force
2.3 N NO changing electrical state
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ZBE1013
Zoro #
G7655008
UPC #
-
Country of Origin
France

Details

Item
N/O Contact With QcS
Standards
IEC 60947-5-4, JIS C8201-5-1, UL 508, CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, JIS C8201-1
[Ui] Rated Insulation Voltage
250 V 3)IEC 60947-1
Protective Treatment
TH
Ambient Air Temperature For Storage
-40-70°C
Operating Force
2.3 N NO changing electrical state
Ambient Air Temperature For Operation
-40-70°C
Vibration Resistance
5 gn 2-500 Hz)IEC 60068-2-6
Operating Travel
2.6 mm NO changing electrical state), 4.3 mm total travel)
Mounting of Block
front mounting
Contact Block Type
single
Contacts Usage
standard contacts
Connections - Terminals
Faston connector 1 x 6.35 mm, Faston connector 2 x 2.8 mm
Ip Degree of Protection
IP20 IEC 60529
Range of Product
Harmony XB5, Harmony XB4
Electrical Composition Code
C1 9 ), C2 7 ), C3 6 ), C4 4 ), C5 5 ), C6 3 ), C7 4 ), C8 2 ), C9 3 ), C12 6 ), M1 6 ), M2 4 ), M3 4 ), M5 2 ), M6 2 ), M7 6 ), M8 4 ), M9 2 ), SF1 3 ), SF2 2 ), MF1 2 ), MF2 2 ), C10 2 ), M4 2 ), C13 1 )
Positive Opening
without
Product or Component Type
contact block
Contact Operation
slow-break
Mechanical Durability
10000000 cycles
Device Short Name
ZBE
Shock Resistance
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Contacts Type And Composition
1 NO
Contacts Material
silver alloy (Ag/Ni)
Product Or Component Type
contact block
Product Certifications
GL || CSA || UL || DNV || LROS (Lloyds register of shipping) || BV
Ip Degree Of Protection
IP20 IEC 60529
Mounting Of Block
front mounting

Description

N/O Contact With QcS
