  13. Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin
Schneider Electric Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin 750XBXH-240A - main

Socket, General Purpose Relay, Octal, 12 A, 8 Pins, Pin

  • Mfr # 750XBXH-240A

  • Zoro # G1001113

product price: $93.59
/ea
Free Shipping & Returns

Key Features

Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
240V AC
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
750XBXH-240A
Zoro #
G1001113
UPC #
-
Country of Origin
China

Dimensions

Overall Height - Relay
2.1 in
Body Width
1.44 in
Body Height
1.62 in
Overall Depth
2.07 in
Body Depth
2.07 in
Width
1.44 in (36.5 mm)
Depth
1.62 in (41.2 mm)

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Pin
Base Shape
Octal
Number of Pins
8
Coil Voltage
240V AC
Current Rating
12 A
Contact Form
DPDT
Contact Rating (AC)
12 A @ 120V, 12 A @ 240V
Contact Rating (DC)
12 A @ 28V
Status Indicator
No Indicator
Socket Code
A
Contact Material
Silver Alloy
Green Environmental Attribute
RoHS 2011/65/EU Compliant
Power Consumption - Relay
2 VA
Standards
CSA Certified, UL Listed
Socket
Mfr. No. 70-464-1, 70-750E8-1
Maximum Operating Temperature
131 Degrees F
Minimum Switching Current
100 mA
Input Voltage
240V AC
Weight
4.59 oz
Operating Current
12 A at 120V AC (Conforming to UL), 12 A at 240V AC (Conforming to UL), 12 A at 28V DC (Conforming to UL)
Pin Shape
Round
Motor Rated
Yes
Response Time
20 msec
Power Consumption
1.2 W, 2.75 VA
Maximum Switching Voltage
300V
Resistance Properties
Shock-Resistant, Vibration-Resistant
IP Rating
IP67
Coil Resistance
7,200 ohm
Horsepower @ 240V AC
1/2 hp
Mechanical Operating Durability
10,000,000
Minimum Operating Temperature
-40 Degrees F
Electrical Operating Durability
100,000
Dielectric Strength
1,500V AC Between Open Contacts, 1,600V AC Between Coil and Contact, 1,600V AC Between Poles
Horsepower @ 120V AC
1/3 hp
Series
750H Haz Location Series
Sealing
Enclosed
Push-To-Test Method
No Test Button
Voltage Range
0.85...1.1 Un AC/DC
Ambient Air Temperature for Storage
-40 to 185°F (-40 to 85°C)
Drop-out Voltage Threshold
>= 0.15 Uc AC; >= 0.1 Uc DC
Product Certifications
UL; CSA
Motor Power HP
0.5 hp 240 V AC 50/60 Hz; 0.33 hp 120 V AC 50/60 Hz
Operating Time
20 ms
Connections Terminals
octal terminal 8 pins)
Power consumption in W
1.2 W DC
Power consumption in VA
2.75 VA AC
Shock Resistance
10 gn
Contact Composition
2 NC + 2 NO
Vibration Resistance
3 gn 35 to 150 Hz)operating; +/- 1 mm 10 to 35 Hz)operating; 6 gn 35 to 150 Hz)not operating; +/- 1 mm 10 to 35 Hz)not operating
Ambient Air Temperature for Operation
-40 to 131°F (-40 to 55°C)

Description

Hermetically Sealed Relay, Base Shape Octal, Coil Voltage 240V AC, Contact Form DPDT, Current Rating 12 A, Electrical Connection 8-Pin Terminal, Flat Pin Width Not Applicable, Number of Pins 8, Pin Shape Round, Sealing Enclosed, Status Indicator No Indicator, Contact Rating (AC) 12 A @ 120V, 12 A @ 240V, Contact Rating (DC) 12 A @ 28V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 1/2 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 2.07 in, Body Height 1.62 in
