  13. Socket, General Purpose Relay, Square, 15 A, 11, Quick-Connect

This item is Discontinued.

Schneider Electric Socket, General Purpose Relay, Square, 15 A, 11, Quick-Connect 8501RS43V20

Socket, General Purpose Relay, Square, 15 A, 11, Quick-Connect (Discontinued)

  • Mfr # 8501RS43V20
  • Zoro # G6127834
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
8501RS43V20
Zoro #
G6127834
UPC #
785901137122
Country of Origin
China

Dimensions

Body Depth - Relay
1.1 in
Body Height - Relay
1.42 in
Overall Height - Relay
1.77 in
Body Width - Relay
1.24 in
Flat Pin Width
0.18 in
Body Width
1.38 in
Body Height
2.77 in
Overall Depth
1.65 in
Body Depth
1.4 in

Details

Item
General Purpose Relay
Mounting Style
Socket
Electrical Connection
Quick-Connect
Base Shape
Square
Number of Pins
11
Coil Voltage
120V AC
Current Rating
15 A
Contact Form
3PDT
Contact Rating (AC)
10 A @ 277V
Contact Rating (DC)
10 A @ 28V
Item - Relay
General Purpose Relay
Power Consumption - Relay
1.2 VA
Standards
CE Certified, CSA Certified, UL Listed
HP @ 240V
1 hp
Contact Material
Silver Alloy
Contact Form - Relay
3PDT
DC Contact Rating - Relay
10A @ 28V
Coil Volts
120V AC
Status Indicator
Mechanical Flag
Base Type - Plug In Relay
Square
Number of Pins - Relay
11
AC Contact Rating - Relay
10A @ 277V
Mounting - Relay
Plug In
Push To Test
No
Mounting
Side
HP @ 120V
1/2 hp
Sealing
Enclosed
Maximum Operating Temperature
131 Degrees F
Motor Rated
Yes
Response Time
20 msec
Compatible with Manufacturer Model Number
8501NR43, 8501NR43B
Minimum Operating Temperature
-40 Degrees F
Series
Square D 8501R Miniature Series
Horsepower @ 120V AC
1/2 hp
Socket Code
E
Power Consumption
1.2 VA
Maximum Switching Voltage
300V AC, 30V DC
Horsepower @ 240V AC
1 hp
Push-To-Test Method
No Button
Pin Shape
Flat
Compatible Manufacturer Part Number
8501NR43, 8501NR43B
Compatible Manufacturer Model Number
8501NR43, 8501NR43B
For Use With Mfr. Model Number
8501NR43, 8501NR43B
Switching Voltage
300 V AC; 30 V DC
Operating Time
20 ms - pick-up || 20 ms - drop-out
Operating Temp. Range
-40-131°F
Compatible with Manufacturer Model No.
8501NR43, 8501NR43B
Compatible with Mfr. Model No.
8501NR43, 8501NR43B
For Use with Mfr Model Number
8501NR43, 8501NR43B
Compatible Pump Manufacturer Part Number
8501NR43, 8501NR43B
Compatible Mfr. Model Number
8501NR43, 8501NR43B

Description

General Purpose Relay, Base Shape Square, Coil Voltage 120V AC, Contact Form 3PDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.18 in, Number of Pins 11, Pin Shape Flat, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 10 A @ 277V, Contact Rating (DC) 10 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.4 in, Body Height 2.77 in, Body Width 1.38 in
