This item is Discontinued.

Schneider Electric Solid State Relay, 90 to 280VAC, 75A 6475AXXSZS-AC90

Solid State Relay, 90 to 280VAC, 75A (Discontinued)

  • Mfr # 6475AXXSZS-AC90
  • Zoro # G3092047
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
6475AXXSZS-AC90
Zoro #
G3092047
UPC #
-
Country of Origin
Mexico

Dimensions

Body Height - Relay
1.4 in
Overall Height - Relay
1.4 in
Body Width - Relay
1.74 in
Body Depth - Relay
2.3 in
Depth
2.30 in (58.4 mm)
Height
1.39 in (35.3 mm)
Width
1.85 in (47.1 mm)
Body Width
1.85 in
Body Depth
2.29 in
Body Height
1.38 in
Overall Depth
2.29 in

Details

Item
Solid State Relay
Switch Type
SCR
Input or Control Voltage Range
90 to 280VAC
Relay Turns On At
Zero Crossing
Item - Relay
Solid State Relay
Input Voltage
90 to 280V AC
Output or Controlled Voltage Range
48 to 480V AC
Max. Output Amps Without Heat Sink
Not Recommended
Finger Safe
Yes
Contact Form - Relay
SPST-NO
Max. Output Amps w/Heat Sink
75 A
Max. Output w/Heat Sink
75A
Mounting - Relay
Surface
Heat Sink
Not Included
Turns On At
Zero Cross
Standards
CE Certified, CSA Certified, UL Listed
Case Color
Gray
Input Power Consumption (Burden)
0.2 to 1.0VA
Mounting
Surface
Input or Control Voltage
90 to 280V AC
Voltage Output
48 to 480VAC
Phase
1
Mounting Style
Panel
Electrical Connection
Screw Clamp
Current Type
AC
Insulation Resistance
1,000 megaohm
Output Voltage Range
48 to 530V AC
Response Time
10 msec
Drop Out Voltage
1.8V DC
Status Indicator
Green LED Indicator
Minimum Operating Temperature
-40 Degrees F
Output Switching Mode
Zero Crossing
Weight
3.7 oz
Electrical Phase
Single
Maximum Operating Temperature
176 Degrees F
Maximum Output Current with Heat Sink
75 A
IP Rating
IP20
Switch Configuration
Form A
Power Factor
1
Switch Component Type
SCR
Maximum Output Current without Heat Sink
Not Recommended
Series
6000 Series
Input Current
2 mA; 4 mA
Dielectric Strength
4,000V
Voltage Type
AC Output
Connections Terminals
Input screw clamp terminal, 1; Output screw clamp terminals, 1
Product Certifications
UL; CSA; CE
Tightening Torque
10 lb.in for input; 20 lb.in for output
Maximum I²t for fusing
4150 A².s 8.3 ms
Screw Type
M3.5; M6
Network Number of Phases
1 phase
Ambient Air Temperature for Operation
-40 to 176°F (-40 to 80°C)
Local Signalling
for input status 1 LED (green)
Protection Technology
Current limiter
Contacts Type and Composition
NO
maximum output current
75 A AC
DV/dt
500 V/µs off-state at maximum rated voltage
Range
Legacy
Input Current Limits
2 mA at 120 V AC typical; 4 mA at 240 V AC typical
Output Voltage
48...530 V AC
Must Release Voltage
10 V
Ambient Air Temperature for Storage
-40 to 257°F (-40 to 125°C)
Voltage Drop
<1.8 V on-state AC
Surge Current
1000 A 16.6 ms
Holding Current
40 mA
Maximum Peak Voltage
800 V
Insulating Resistance
1 GΩ
Thermal Resistance
0.28°C/W
Input Impedance
60 kOhm
Leakage Current
10 mA at off-state
Control Circuit Voltage
90...280 V AC
Switching Device
SCR output; Zero voltage switching
Switch Function
SPST
Maximum I²t for fusing
4150 A².s 8.3 ms

Description

Solid State Relay, Electrical Connection Screw Clamp, Heat Sink Not Included, Input Current 2 mA; 4 mA, Input Voltage 90 to 280V AC, Maximum Output Current with Heat Sink 75 A, Maximum Output Current without Heat Sink Not Recommended, Output Switching Mode Zero Crossing, Output Voltage Range 48 to 530V AC, Standards CE Certified, CSA Certified, UL Listed, Switch Component Type SCR, Current Type AC, Electrical Phase Single, Finger Safe Yes, Mounting Style Panel, Switch Configuration Form A
