Schneider Electric Switch Loadbreak Mod VZ2 - main

Switch Loadbreak Mod

  • Mfr # VZ2

  • Zoro # G0984541

product price: $58.15
/ea

Key Features

For Use With
Tesys Vario Series
Disconnect Switch Size
0.625 A
Height
2.91 in
Depth
1.38 in
Standards
IEC 60947-3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
VZ2
Zoro #
G0984541
UPC #
785901305668
Country of Origin
Czechia

Dimensions

Disconnect Switch Size
0.625 A
Height
2.91 in
Depth
1.38 in
Width
0.63 in

Details

Item
Nonfusible Loadbreak
For Use With
Tesys Vario Series
Standards
IEC 60947-3
Product Type
Additional Pole
Compatible with Manufacturer Model Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Current Rating
40 A
Color
Gray
Mounting Mechanism
DIN Rail
Maximum Voltage
690V AC
Compatible Manufacturer Part Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Compatible Grainger Part Number
615A62, 615A64, 615A66, 615A67, 615A70
Compatible Manufacturer Model Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
For Use With Mfr. Model Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Mechanical Robustness
vibrations 10 to 150 Hz 1 gn) IEC 60068-2-6 || shocks 11 ms 30 Gn) IEC 60068-2-27
Product Or Component Type
additional pole
Range Compatibility
TeSys (TeSys VARIO) switch disconnector
Mechanical Durability
100000 cycles
Contacts Type And Composition
1 NO
[Ith] Conventional Free Air Thermal Current
40 A
Suitability For Isolation
yes
Electrical Durability
100000 cycles AC-21 || 30000 cycles DC-1 to 5
Mounting Location
right || left
Device Short Name
VZ
[Uimp] Rated Impulse Withstand Voltage
8 kV
Connections - Terminals
power circuit screw clamp terminals 6-6 mm² flexible - with cable end || power circuit screw clamp terminals 10-10 mm² solid
Ip Degree Of Protection
IP20 conforming to IEC 60529
Ambient Air Temperature For Operation
-20-50°C
Protective Treatment
TC
[Ue] Rated Operational Voltage
690 V AC 50/60 Hz
[Ithe] Conventional Enclosed Thermal Current
32 A
Network Type
AC || DC
Poles Description
1P
Product Certifications
CSA || GL || UL || UKCA
Product Compatibility
V2
Network Frequency
50/60 Hz
Range
TeSys
Tightening Torque
power circuit 2.1-2.1 N.m screw clamp terminals
Fire Resistance
960°C IEC 60695-2-1
Performance Level
high performance
Compatible with Manufacturer Model No.
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Compatible with Mfr. Model No.
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
For Use with Mfr Model Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Compatible Pump Manufacturer Part Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1
Compatible Mfr. Model Number
VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1

Description

Nonfusible Loadbreak, Color Gray, Compatible with Grainger Part Number 615A62, 615A64, 615A66, 615A67, 615A70, Compatible with Manufacturer Model Number VLS3P016R1, VLS3P025R1, VLS3P032R1, VLS3P040R1, VLS3P063R1, Current Rating 40 A, Depth 1.38 in, For Use With Tesys Vario Series, Height 2.91 in, Maximum Voltage 690V AC, Mounting Mechanism DIN Rail, Product Type Additional Pole, Standards IEC 60947-3, Width 0.63 in
