  6. Variable Frequency Drive, 15 HP, 575-690V

This item is Discontinued.

Schneider Electric Variable Frequency Drive, 15 HP, 575-690V ATV61HD15Y

Variable Frequency Drive, 15 HP, 575-690V (Discontinued)

  • Mfr # ATV61HD15Y
  • Zoro # G0105345
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
ATV61HD15Y
Zoro #
G0105345
UPC #
785901865520
Country of Origin
France

Dimensions

Overall Height
16 5/8 in
Overall Depth
9 3/8 in
Overall Width
9 1/2 in

Details

Item
Variable Speed Drive
Max. HP
15 hp
Input Voltage
690V AC
Output Voltage
690V AC
Input Phase AC
Three
Enclosure
Totally Enclosed
Max. Output Amps
17 A
Output Phase AC
Three
With Bypass / No Bypass
No Bypass
With Line Contactor / No Line Contactor
No Line Contactor
Accepts Input Control Signal
Yes
Input Frequency
50/60 Hz
Digital Readout
Yes
Dynamic Braking
No
Display Type
LCD
Displays
LCD Keypad
Protection
Against exceeding limit speed, Against input phase loss, Break on the control circuit, Input phase breaks, Line supply overvoltage, Line supply undervoltage, Motor phase break, Overcurrent between output phases and earth, Overheating protection, Overvoltage's on the DC bus, Power removal, Short-circuit between motor phases, Thermal protection
Control Type
Keypad, Remote
Output Frequency Range
0.1 to 500 Hz
Start/Stop Control
Programmable
Key Pad Lockout
None
Standards
EN/IEC 61800-3, IEC 60721-3-3 Class 3C2, EN 61800-3 Environments 2 Category C3, EN 55011 Class A Group 2, EN 61800-3 Environments 1 Category C3, UL Type 1, EN/IEC 61800-5-1
Control Method
Keypad, Remote
Maximum Output Power
20 hp
Maximum Output Current
18.5 A
Adjustable Deceleration Time
0.01 to 9,000 sec
Application
Pumping and Ventilation Machine
Adjustable Acceleration Time
0.01 to 9,000 sec

Description

Variable Speed Drive, Input Voltage 690V AC, Input Phase AC Three, Input Frequency 50/60 Hz, Maximum Output Power 20 hp, Maximum Output Current 18.5 A, Output Voltage 690V AC, Output Phase AC Three, Output Frequency Range 0.1 to 500 Hz
