Securitron ElectromgntcLck, Camera, 600lb, MotionSnsor M380BDC2X

ElectromgntcLck, Camera, 600lb, MotionSnsor (Discontinued)

  • Mfr # M380BDC2X
  • Zoro # G0159008
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
M380BDC2X
Zoro #
G0159008
UPC #
-
Country of Origin
United States

Dimensions

Lock Body Width
2 3/16 in
Armature Width
2 3/16 in
Strike Plate Depth
1/2 in
Armature Length
10 in
Lock Body Depth
2 7/16 in
Lock Body Length
10 in
Armature Depth
2 7/16 in
Strike Plate Width
1 5/8 in
Strike Plate Length
7 7/16 in

Details

Item
Electromagnetic Lock
Camera Type
Color
Finish
Satin Aluminum
Options Included
BondSTAT Lock Bond Sensor, Color Camera, Request to Exit Sensor
Day/Night Capable
Day
Min. Light Level
1.5 Lux
Holding Force
600 lb
Includes
Mounting brackets
Lock Power Consumption
12V DC @ 550mA or 24V DC @ 300mA
Material
Steel
Mfr. Series
380
S/N Ratio (dB)
48
Standards
UL 10C, UL 1034, CAN4-S104, ANSI/BHMA A156.23, Grade 1;E18501-500, E18531-500, CSFM
Camera Power Consumption
12V DC @ 200mA or 24V DC @ 80mA
Viewing Angle
112 Degrees
Line Resolution
B/W 420 TV Line, Color 520 TV Line
Lock Voltage
12V DC or 24V DC
Camera Voltage
12V DC or 24V DC
Features
LED Visual Locked Status with Configurable Red/Green Color Output, Bracket Mounting, Integrated Door Position Switch, Autosensing Dual Voltage with Microprocessor Technology, Adjustable Automatic Relock Timer (0.5-15 sec), Wire Chamber with Anti-Tamper Switch, Efficient, Low Power Usage
Release Delay
Zero

Description

Electromagnetic Lock,Camera Type Color Camera,600 lb. Holding Force,Options Included BondSTAT Lock Bond Sensor, Color Camera, Request to Exit Sensor,Day/Night Capable Day,Min. Light Level 1.5 Lux,Lock Body Length 10 In.,Lock Body Width 2-3/16 In.,Lock Body Depth 2-7/16 In.,Strike Plate Length 7-7/16 In.,Strike Plate Width 1-5/8 In.,Strike Plate Depth 1/2 In.,Material Steel,Satin Aluminum Finish,Lock Voltage 12VDC or 24VDC,Camera Voltage 12VDC or 24VDC,Mfr. Series 380
