4" FNPT Ductile Iron Oil Patch Swing Check Valve

  • Mfr # 4353014500
  • Zoro # G5032587
product price:
$
648.99
/ea
Free Shipping & Returns

Key Features

Pipe Size
4"
Connection Type
FNPT
Body Material
Ductile Iron
Size
4"
Max. Water Pressure - Valves
2000 psi @ 250 Degrees F
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
4353014500
Zoro #
G5032587
UPC #
-
Country of Origin
China
Connection Type
FNPT
Body Material
Ductile Iron
Max. Water Pressure - Valves
2000 psi @ 250 Degrees F
Seal Material
FKM
Cracking Pressure
0 psi
Max. Pressure
750 psi
Max. Temp. - Valves
280 Degrees F
Seal Material - Check Valves
Viton
Mounting Position
Horizontal
Body Material - Valves
Ductile Iron
Flow - Valves
400 gpm
Max. Steam Pressure - Valves
Not Rated
Full Flow - Valves
Yes
Standards
NACE MR0175
Sub-Category
Iron
Cracking Pressure - Check Valves
0 psi
Application - Valves
General Purpose
Mounting Orientation - Check Valves
Horizontal
Connection Type - Check Valves
FNPT x FNPT
Item - Check Valves
Check Valve
Seat Material - Check Valves
Viton
Seat Material
Rubber
Material of Construction
Ductile Iron
Min. Temp. - Valves
0 Degrees F
Compliance
NACE MR0175-2009
Item
Oil Patch Swing Check Valve
Mechanism and Body Design
Inline Swing
Max. Temp.
0 Degrees to 280 Degrees F
Flow Design
Single
Flow
400 gpm
Mounting Orientation
Horizontal
Silent Check
Standard
Valve Body Style
Inline
Maximum Pressure - Operating
2,000 psi
Includes Counterweight
No Counterweight
Check Mechanism Material
316 Stainless Steel
Valve Ways
2-Way
For Media
Oil
Connection Gender - Side 1
Female
Vacuum Service Rating
Not Rated
Check Mechanism
Swing
Operating Temperature - Maximum
280 Degrees F
Connection Type - Side 1
NPSM
Connection Gender - Side 2
Female
Connection Type - Side 2
NPSM
3-A Standard Compliance
Not Rated
Maximum Pressure - Steam
Not Rated
Operating Temperature - Minimum
0 Degrees F
Valve Series
OP20

Description

The SHARPE 4353014500 is a 4 in oil patch swing check valve with an inline ductile iron body and FNPT x FNPT connections. It is designed for one-direction flow and uses a swing check mechanism for reverse-flow control in oil service and compatible piping applications within the specified ratings. The valve features a single full-flow design, a 0 psi cracking pressure, a 400 gpm flow rating, and is specified for horizontal mounting.

Key Features:

  • Valve type: Oil patch swing check valve with inline swing mechanism
  • Size: 4 in nominal valve size with 4 in connections on both sides
  • Connections: Female FNPT x FNPT
  • Body material: Ductile iron
  • Check mechanism material: 316 stainless steel
  • Seal material: Viton
  • Seat material: Viton
  • Flow design: Single, full flow
  • Cracking pressure: 0 psi
  • Flow rating: 400 gpm
  • Temperature range: 0 Degrees F to 280 Degrees F
  • Mounting orientation: Horizontal
  • Standards: NACE MR0175; NACE MR0175-2009
  • Valve series: OP20
  • Overall length: 10 in
