  11. 2" X 13/16" Non-Marking Polyolefin Rigid Caster, No Brake, Loads Up To 125 lb
Shepherd Hardware 2" X 13/16" Non-Marking Polyolefin Rigid Caster, No Brake, Loads Up To 125 lb PRQ20122ZN-3E - main

2" X 13/16" Non-Marking Polyolefin Rigid Caster, No Brake, Loads Up To 125 lb

  • Mfr # PRQ20122ZN-3E

  • Zoro # G7811678

product price: $2.75
/ea

Key Features

Caster Sub-Type
Rigid
Wheel/Tread Material
Polyolefin
Caster Brake Type
No Brake
Wheel Dia.
2 in
Wheel Width
7/8 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PRQ20122ZN-3E
Zoro #
G7811678
UPC #
-
Country of Origin
China

Dimensions

Wheel Dia.
2 in
Wheel Width
7/8 in
Mounting Height
2-1/2 in
Mounting Plate Size
1 1/2 in x 2 21/32 in
Mounting Plate Thickness
3/32 in
Mounting Bolt Dia.
1/4 in
Hub Length
29/32 in
For Axle Dia.
1/4 in
Bolt Hole Spacing - Width
0.938 in
Bolt Hole Spacing - Length
2.125 in
Mounting Plate Width
1 1/2 in
Mounting Plate Length
2 21/32 in

Details

Item
Rigid Caster
Caster Sub-Type
Rigid
Wheel/Tread Material
Polyolefin
Caster Brake Type
No Brake
Load Rating
125 lb
Caster Mounting Type
Plate
Wheel Bearing Type
Plain
Wheel/Tread Color
Black
Wheel Hardness Rating
70 Shore D
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Grey
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
15/16 in X 2-1/8 in
Inside Bolt Hole Spacing
15/16 in X 2-1/8 in
Caster Plate Hole Pattern
D
ESD Conductive
No
Features
Economical Mobility Solution
Application
Store Fixtures, Furniture, Material Handling, Institutional Equipment, Industrial Equipment
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood
Swivel Lock Type
No Lock Included
Wheel Core Type
Solid
Wheel Core Material
Polyolefin
Caster Stem Type
Top Plate
Operating Temperature Range
-20 to 180 Degrees F
NSF Listed
No
Standards
RoHS Compliant, NSF Listed
Series
General Duty
Frame Finish
Zinc Plated
Frame Color
Silver
Load Rating Range
0 to 299 lb
Includes Thread Guards
No
Wheel/Tread Hardness Rating
Hard
Load Capacity - Maximum
125 lb
Mounting Hole Type
Hole
Mounting Plate Shape
Rectangle

Description

Rigid, Plate Caster, Load Rating 125 lb, Swivel Lock Type No Lock Included, Wheel Dia. 2 in, Wheel Width 7/8 in, Wheel/Tread Material Polyolefin, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
