  6. 2" X 13/16" Non-Marking Pvc Swivel Caster, No Brake, Loads Up To 90 lb
Shepherd Hardware 2" X 13/16" Non-Marking Pvc Swivel Caster, No Brake, Loads Up To 90 lb PRE20634ZN-VPR01(CG) - main

2" X 13/16" Non-Marking Pvc Swivel Caster, No Brake, Loads Up To 90 lb

  • Mfr # PRE20634ZN-VPR01(CG)

  • Zoro # G7806778

product price:  $5.69
/ea

Key Features

Caster Stem Type
Threaded Stem
Tread Shape
Donut
Wheel Width
13/16 in
Mounting Height
2-5/8 in
Load Rating
90 lb
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PRE20634ZN-VPR01(CG)
Zoro #
G7806778
UPC #
-
Country of Origin
United States

Dimensions

Wheel Width
13/16 in
Mounting Height
2-5/8 in
Stem Length
1 in
Thread Size
16UNC
Overall Height
3 5/8 in
Stem Dia.
3/8 in
Caster Stem Size
3/8"-16 x 1 in
Wheel Dia.
2 in

Details

Item
Quality Economic Light Duty Threaded Stem Caster
Caster Stem Type
Threaded Stem
Tread Shape
Donut
Load Rating
90 lb
Load Rating Range
0 to 299 lb
Wheel/Tread Material
Pvc
Application
Store Fixtures, Carts, Institutional Equipment, Food Serive Equipment, Furniuture, Janitorial , Office Equipment, Racks And Storage Equipment, Medical Equipment
Non-Marking
Yes
Caster Brake Type
No Brake
Caster Frame Material
Steel
Wheel Bearing Type
Plain Bore (None)
Number of Wheels
1
Features
Octagon Washer for Easy Installation, High Strength, Durability, Resistant to Chemicals and Oils
System of Measurement
Inch
Series
Regent
Caster Mounting Type
Stem
Frame Finish
Zinc Plated
Swivel Raceway Type
Double Ball
Caster Product Group
Swivel Caster
Caster Sub-Type
Swivel
Swivel Lock Type
No Lock Included
Wheel/Tread Color
Clear
Standards
NSF Approved, RoHS Compliant
Core Color
Gray
Includes Spanner Bushing
No
Wheel Type
Tread on Core
Operating Temperature - Maximum
180 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Wheel Core Type
Solid
Number of Mounting Holes
0
For Surface Type
Asphalt, Ceramic, Grease, Oil, Rubber, Steel, Tile, Vinyl, Wood
Load Capacity - Maximum
90 lb
Wheel Hardness Rating
90 Shore A

Description

Stem Caster, Swivel Caster, 90 lb Load Rating, 0 to 299 lb, 2 in Wheel Dia., 13/16 in Wheel Width, Polyurethane Wheel/Tread Material, 2 5/8 in Mounting Height, Plain, 3/8 In.-16 x 1 in Caster Stem Size, Threaded, Steel Caster Frame Material, Zinc Plated Frame Finish, Yes Non-Marking, 1 Number of Wheels
