Definite Purpose Contactor, 208V-240V AC, 3 P, Non-Reversing, 3 Phase, Quick Connect & Screw

  • Mfr # 42BF35AG
  • Zoro # G208841853
product price:
$
102.99
/ea
Free Shipping & Returns

Key Features

Coil Voltage
190V AC to 220V AC, 208V AC to 240V AC
Series
42BF
Number of Poles
3
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
42BF35AG
Zoro #
G208841853
UPC #
783087145061
Country of Origin
China

Dimensions

Overall Depth
2.87 in
Overall Width
2.38 in
Mounting Hole Distance - Height
3.25 in
Overall Height
3.69 in
Mounting Hole Distance - Width
1.98 in

Details

Item
Definite Purpose Contactor
Coil Voltage
190V AC to 220V AC, 208V AC to 240V AC
Series
42BF
Number of Poles
3
Reversing Capability
Non-Reversing
Full Load Current - Resistive
40 A
Full Load Current - Inductive
30 A
Phase
3
Terminal Connection Type
Quick Connect & Screw
Standards
ARI 780, ARI 790, cRUus, UL E14900
Mounting Postion
Vertical
Resistance Properties
Weld Resistant
Horsepower @ Three Phase - 208V AC
1/2 hp
Horsepower @ Single Phase - 240V AC
3 hp
Frequency
50/60 Hz
Locked Rotor Load
120 A @ 600V, 150 A @ 480V, 180 A @ 240V
Maximum Voltage Rating
600V AC
Number of Normally Open Main Contacts
3
Horsepower @ Single Phase - 120V AC
Not Rated
Horsepower @ Three Phase - 480V AC
10 hp
Mounting Style
Surface
Status Indicator
Mechanical Flag
Contact Material
Silver Cadmium Oxide
Auxiliary Contact Module Capacity
4
Horsepower @ Three Phase - 600V AC
15 hp
Horsepower @ Three Phase - 240V AC
7 1/2 hp
NEMA Enclosure Rating
No Enclosure
Mechanical Operating Durability
250,000
Maximum Operating Temperature
158 Degrees F

Description

Definite Purpose Contactor, LED Lighting Current Rating Not Applicable, Coil Voltage 190-220/208-240V AC, Series 42 Series, Number of Poles 3, NEMA Enclosure Rating No Enclosure, Tungsten Lighting Current Rating Not Applicable, Fluorescent Lighting Current Rating Not Applicable, Reversing Capability Non-Reversing, Frame Size Not Applicable, Horsepower @ Single Phase - 240V AC 3 hp, Horsepower @ Single Phase - 120V AC Not Rated, Full Load Current - Resistive 40 A
