Siemens Definite Purpose Magnetic Contactor, 440V-480V AC, 2 P, Non-Reversing, 1 Phase, Screw 45GG20AH - main

Definite Purpose Magnetic Contactor, 440V-480V AC, 2 P, Non-Reversing, 1 Phase, Screw

  • Mfr # 45GG20AH

  • Zoro # G8359925

product price:  $89.99
/ea
Free Shipping & Returns

Key Features

Coil Voltage
440V-480V AC
Series
45GG
Number of Poles
2
Reversing Capability
Non-Reversing
Full Load Current - Resistive
50 A
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
45GG20AH
Zoro #
G8359925
UPC #
783087208209
Country of Origin
China

Dimensions

Width
1.97 in
Depth
2.46 in
Height
3.19 in
Mounting Hole Distance - Height
1.77 in
Mounting Hole Distance - Width
1.61 in
Overall Width
1.97 in
Overall Height
3.19 in
Overall Depth
2.46 in

Details

Item
Definite Purpose Magnetic Contactor
Coil Voltage
440V-480V AC
Series
45GG
Number of Poles
2
Reversing Capability
Non-Reversing
Full Load Current - Resistive
50 A
Full Load Current - Inductive
40 A
Phase
1
Terminal Connection Type
Screw
Enclosure NEMA Rating
No Enclosure
Standards
REACH Art 33
Reversing
No
Maximum Voltage Rating
600V AC
Horsepower @ Single Phase - 120V AC
3 hp
Horsepower @ Three Phase - 600V AC
Not Rated
Contact Material
Silver Cadmium Oxide
Frequency
50/60 Hz
Number of Normally Open Main Contacts
2
Mounting Postion
Vertical
Resistance Properties
Weld Resistant
Horsepower @ Three Phase - 240V AC
10 hp
Locked Rotor Load
240 A @ 240V, 240 A @ 277V
Horsepower @ Single Phase - 240V AC
5 hp
NEMA Enclosure Rating
No Enclosure
Mechanical Operating Durability
250,000
Maximum Operating Temperature
158 Degrees F
Auxiliary Contact Module Capacity
0
Number of Normally Closed Main Contacts
0
Mounting Style
Surface

Description

Definite Purpose Magnetic Contactor, LED Lighting Current Rating Not Applicable, Coil Voltage 380-440/440-480V AC, Series 42 Series, Number of Poles 2, NEMA Enclosure Rating No Enclosure, Tungsten Lighting Current Rating Not Applicable, Fluorescent Lighting Current Rating Not Applicable, Reversing Capability Non-Reversing, Frame Size Not Applicable, Horsepower @ Single Phase - 240V AC 5 hp, Horsepower @ Single Phase - 120V AC 3 hp, Full Load Current - Resistive 50 A

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
