Siemens Electronic Module 6ES71314BD010AA0 6ES7131-4BD01-0AA0 - main

Electronic Module 6ES71314BD010AA0

  • Mfr # 6ES7131-4BD01-0AA0

  • Zoro # G008131666

product price: $626.99
/ea
Free Shipping & Returns

Key Features

Height
81 millimetre
Depth
52 millimetre
Width
15 millimetre
Number of HW interfaces PROFINET
0
Number of HW interfaces serial RS422
0
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
6ES7131-4BD01-0AA0
Zoro #
G008131666
UPC #
662643216974
Country of Origin
Germany

Dimensions

Height
81 millimetre
Depth
52 millimetre
Width
15 millimetre

Details

Number of HW interfaces PROFINET
0
Number of HW interfaces serial RS422
0
min. supply voltage with DC
20 volt
Number of HW interfaces Industrial Ethernet
0
Number of HW interfaces Wireless
0
wall mounting/direct mounting possible
No
Number of inputs
4
Field bus connection possible via separate bus couplers
Yes
Rack-assembly possible
No
Input voltage, type
DC
Number of inputs, digital
4
Number of outputs, digital
0
Manufacturer product root
Digital module input
digital inputs, configurable
Yes
Number of HW interfaces, other
0
Max. delay time with change of signal
5 millisecond
Number of outputs
0
max. permissible voltage at input
30 volt
Bearing track assembly possible
Yes
Number of HW interfaces parallel
0
Power loss, static, current-independent [Pls]
1 watt
Input current for state 1
7 milliampere
Optical interface present
No
Manufacturer product family
ET 200S
Supply voltage type
DC
Front installation possible
No
Design of electrical connection
Screw/spring connection
Number of HW interfaces serial TTY
0
Protection type IP
IP20
Number of HW interfaces serial RS485
0
max. supply voltage with DC
28.8 volt
min. permissible voltage at input
-30 volt
Explosion protection categories for gases
ATEX gas-ex-protection, Cat. 3
description of product type
4DI 24 V DC ST
Number of HW interfaces serial RS232
0
Min. delay time with change of signal
2 millisecond
System components present
Yes

Description

6Es71314Bd010Aa0 Electronic Module For Et 200S 4 Digital Inputs 24 Vdc 15 Mm Width
