  11. Electronic Module 6ES71314BD010AA0
This item is Discontinued.
Siemens Electronic Module 6ES71314BD010AA0 6ES7131-4BD01-0AA0

Electronic Module 6ES71314BD010AA0 (Discontinued)

  • Mfr # 6ES7131-4BD01-0AA0
  • Zoro # G608131660
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
6ES7131-4BD01-0AA0
Zoro #
G608131660
UPC #
-
Country of Origin
Germany

Dimensions

Depth
52 millimetre
Width
15 millimetre
Height
81 millimetre

Details

min. permissible voltage at input
-30 volt
Number of HW interfaces Industrial Ethernet
0
Max. delay time with change of signal
5 millisecond
Number of HW interfaces serial RS422
0
Number of HW interfaces PROFINET
0
Optical interface present
No
Rack-assembly possible
No
Number of outputs, digital
0
Front installation possible
No
max. supply voltage with DC
28.8 volt
System components present
Yes
Number of HW interfaces parallel
0
Input current for state 1
7 milliampere
Number of inputs
4
Protection type IP
IP20
Manufacturer product family
ET 200S
wall mounting/direct mounting possible
No
Number of HW interfaces, other
0
digital inputs, configurable
Yes
Number of inputs, digital
4
Supply voltage type
DC
Number of HW interfaces Wireless
0
Bearing track assembly possible
Yes
max. permissible voltage at input
30 volt
Explosion protection categories for gases
ATEX gas-ex-protection, Cat. 3
Input voltage, type
DC
Power loss, static, current-independent [Pls]
1 watt
Manufacturer product root
Digital module input
description of product type
4DI 24 V DC ST
Field bus connection possible via separate bus couplers
Yes
Number of outputs
0
Number of HW interfaces serial RS232
0
min. supply voltage with DC
20 volt
Number of HW interfaces serial RS485
0
Number of HW interfaces serial TTY
0
Design of electrical connection
Screw/spring connection
Min. delay time with change of signal
2 millisecond

Description

6Es71314Bd010Aa0 Electronic Module For Et 200S 4 Digital Inputs 24 Vdc 15 Mm Width 5 Units Per Packing Unit
