Molded Case Circuit Breaker, JXD2-A Series, 300A, 2 Pole, 240V AC, 65kA at 240V AC
Mfr # JXD22B300
Zoro # G3091873
product price:Â $5,917.99
/ea
Free Shipping & Returns
Key Features
Series
JXD2-A
Number of Poles
2
AC Voltage Rating
240V AC
Circuit Breaker Type
Standard
Phase
1
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- JXD22B300
- Zoro #
- G3091873
- UPC #
- 783643212893
- Country of Origin
- Mexico
Dimensions
- Frame Size
- 400A/JD
- Width
- 7-1/2 in
- Depth
- 4 in
- Height
- 11 in
- Max. Wire Size
- 500 MCM
Details
- Item
- Molded Case Circuit Breaker
- Series
- JXD2-A
- Amps
- 300A
- Number of Poles
- 2
- AC Voltage Rating
- 240V AC
- Circuit Breaker Type
- Standard
- Phase
- 1
- Circuit Breaker Actuator
- Toggle
- Circuit Breaker Mounting Style
- Free Standing
- Max. AIR Rating
- 65kA at 240V AC
- Trip Type
- Thermal Magnetic
- Instantaneous Trip
- Fixed
- Terminal Connection
- Lugs
- DC Voltage Rating
- 250V DC
- High Amp Trip Setting
- 300 A
- Low Amp Trip Setting
- 300 A
- For Use With
- SB Switchboards Without Lugs, Sentron Panelboards
- Standards
- HACR Rated, UL Listed
Description
Molded Case Circuit Breaker, 300 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 65kA at 240V AC, For Use With SB Switchboards Without Lugs, Sentron Panelboards, Series JXD2-A, High Amp Trip Setting 300 A, Low Amp Trip Setting 300 A, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 250V DC, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection Not Applicable, Frame Size 400A/JD
