Siemens Push Button, 22mm, Blue, Metal Bezel 3SU1150-0BB50-1FA0 - main

Push Button, 22mm, Blue, Metal Bezel

  • Mfr # 3SU1150-0BB50-1FA0

  • Zoro # G3040602

product price: $25.29
/ea

Key Features

Material
metal
Color
Blue
Bezel
Metal
Contact Rating
10A @ 600V AC, 1A @ 600V DC
Terminal Connection
Screw
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
3SU1150-0BB50-1FA0
Zoro #
G3040602
UPC #
804766359187
Country of Origin
Germany

Dimensions

Size
22 mm
Overall Depth
3.46 in
Panel Cutout Diameter
22 mm
Manufacturer Warranty Length
1 yr
Overall Height
1.57 in
Overall Width
1.18 in

Details

Item
Extended Push Button Operator
Material
metal
Color
Blue
Bezel
Metal
Contact Rating
10A @ 600V AC, 1A @ 600V DC
Terminal Connection
Screw
Contact Form
1NO/1NC
Number of Operators
1
NEMA Contact Rating Designation
A600/R300
IP Rating
IP66, IP67, IP69, IP69K
Action
Momentary
Type of Operator
Extended Button
Basic Material
Zinc Alloy
NEMA Rating
1, 12, 2, 3, 3R, 4, 4X
Head Material
Plastic
Standards
REACH, WEEE (2012/19/EU)
Features
Possible to Select 1 to 4 Positions with ID Keys, Four ID Keys with Different Codes
Product Type
Push Button Operators
Bezel Material
Metal
Type
Pushbuttons
Application
Complete unit
Operating Temperature
-25°C to 70°C
Insulation
IP66, IP67, IP69(IP69K)
Environmental Conditions
-25
Mounting
front plate mounting
Number of Poles
1
Special Features
Yes
Contact configuration
36526
Voltage rating
5
Connection
screw-type terminals
Actuator
Button, raised
Operating cycles
10000000
Series
3SU
Operating Temperature - Maximum
158 Degrees F
Operator Material
Zinc Alloy
Operator Illumination
Non-Illuminated
Head Color
Blue
Operator Voltage Rating - Maximum
500 V
Operating Temperature - Minimum
-13 Degrees F
NEMA Enclosure Rating
1, 12, 2, 3, 3R, 4, 4X
Push Button Style
Extended
AC Contact Rating
10 A @ 600 V
DC Contact Rating
1 A @ 600 V
Mechanical Operating Durability
1.00 x 10^7
Number of Indicator Lights
0

Description

Extended Push Button Operator, 22 mm, Momentary Action, Extended Button Type of Operator, Head Material Plastic, Contact Form 1NO/1NC, Bezel Metal, Color Blue, Contact Rating 10A @ 600V AC, 1A @ 600V DC, NEMA Contact Rating Designation A600/R300, Number of Operators 1, NEMA Rating 1, 12, 2, 3, 3R, 4, 4X, IP Rating IP66, IP67, IP69, IP69K, Legend Not Applicable, Standards REACH, WEEE (2012/19/EU), Terminal Connection Screw
