MECHANICAL VALVE
Mfr # VM1100-4N-00
Zoro # G015196979
product price:Â
$
16.19
/ea
Key Features
Series
VM1000
Overall Height
20 7/8 mm
Overall Length
36 1/8 mm
Overall Width
11 mm
Seal Material
Buna-N
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- VM1100-4N-00
- Zoro #
- G015196979
- UPC #
- -
- Country of Origin
- Japan
- Item
- Shuttle Valve
- Series
- VM1000
- Seal Material
- Buna-N
- Body Material
- Aluminum
- Valve Action
- Normally Closed
- For Media
- Air
- Standards
- RoHS Compliant
- Operating Temperature - Maximum
- 60 Degrees C
- Coefficient of Volume (Cv)
- 0.055
- Operating Pressure - Minimum
- 0 MPa
- Body Style
- Side-Ported
- Operating Pressure - Maximum
- 0.8 MPa
- Valve Type
- Poppet
- Number of Ports
- 2
- Lubrication
- Lubrication Not Required
- Operating Temperature - Minimum
- -5 Degrees C
- Valve Port Connection Type
- Push-On
- Actuator Type
- Plunger
Description
Shuttle Valve, Body Material Aluminum, Overall Length 36 1/8 mm, Overall Height 20 7/8 mm, Overall Width 11 mm, Series VM1000
