Medium Stroke Gripper, 12mm Bore
Mfr # MHF2-12D1
Zoro # G4999891
product price:Â $380.99
/ea
Free Shipping & Returns
Key Features
Standards
RoHS Compliant
Repeatability
+/-0.05 mm
Minimum Operating Pressure
15 psi
Inlet Size
M5 x 0.8
Stroke Length
24 mm
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- MHF2-12D1
- Zoro #
- G4999891
- UPC #
- 00713049196862
- Country of Origin
- Japan
Dimensions
- Inlet Size
- M5 x 0.8
- Stroke Length
- 24 mm
- Open Width
- 24 mm
- Overall Height
- 25 mm
- Overall Length
- 40 mm
- Overall Width
- 68 mm
- Bore Diameter
- 12 mm
- Wire Rope Length
- 40 mm
Details
- Item
- Medium Stroke Gripper
- Standards
- RoHS Compliant
- Repeatability
- +/-0.05 mm
- Minimum Operating Pressure
- 15 psi
- Maximum Operating Temperature
- 140 Degrees F
- Finger Material
- Stainless Steel
- System of Measurement
- Metric
- Weight
- 190 g
- Series
- MHF2
- Minimum Operating Temperature
- 14 Degrees F
- Maximum Operating Pressure
- 101 psi
- Body Material
- Aluminum
- Body Material Finish
- Hard Anodized
- Seal Material
- Nitrile
Description
Medium Stroke Gripper, Series MHF2, Open Width 24 mm, Stroke Length 24 mm, Maximum Operating Pressure 101 psi, Minimum Operating Pressure 15 psi, Overall Length 40 mm, Overall Width 68 mm, Overall Height 25 mm, Body Material Aluminum, Finger Material Stainless Steel, Inlet Size M5 x 0.8, Maximum Operating Temperature 140 Degrees F, Minimum Operating Temperature 14 Degrees F, Standards RoHS Compliant, Weight 190 g, Body Material Finish Hard Anodized, System of Measurement Metric
