Smc

Speed Exhaust Control Valve, 4mm, M5x0.8

product price: $16.59
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Valve Style Elbow
  • Pipe Size M5 x 0.8
  • Valve Port Size M5 x 0.8
  • Valve Tube Size 4 mm
  • Connection NPT x Tube
See all product information

Product Information

Dimensions

Pipe Size M5 x 0.8
Valve Port Size M5 x 0.8
Valve Tube Size 4 mm
Valve Body Size M5
Tube Size 4mm
Air Connection Size 4 mm
Connection Size 10-32

Details

Valve Style Elbow
Item Speed Exhaust Control Valve
Connection NPT x Tube
Connection Type UN
Body Material Stainless Steel
Valve Flow Out
Body Material - Valves Nickel-Plated Brass
Temp. Range 23 Degrees to 140 Degrees F
Adjustment Screw
Style Elbow
Pressure Range 14.5 to 145 psi
Flow Out
Standards UL standard V-0
Seal Material NBR
Fitting Style Elbow
Adjustment Type Screw
Minimum Operating Temperature -5 Degrees C
Minimum Operating Pressure 14.5 psi
Metering Direction Meter Out
Air Connection Type Push to Connect Tube
Connection Gender Female
Maximum Flow Rate 8.1 cfm
Maximum Operating Temperature 60 Degrees C
Maximum Operating Pressure 145 psi
Body Material Finish Nickel Plated

Description

Speed Exhaust Control Valve, Adjustment Type Screw, Valve Body Size M5, Air Connection Size 4 mm, Connection Type UN, Connection Gender Female, Connection Size 10-32, Air Connection Type Push to Connect Tube, Metering Direction Meter Out, Body Material Stainless Steel, Maximum Operating Pressure 145 psi, Minimum Operating Pressure 14.5 psi, Maximum Flow Rate 8.1 cfm, Minimum Flow Rate Not Applicable, Fitting Style Elbow, Body Material Finish Nickel Plated
