  9. Polycrystalline Solar Panel, 10 W, 17.3V DC, 0.59 A, 36 Cells, Open End
Shop All Solar Panels
Solartech Power

Polycrystalline Solar Panel, 10 W, 17.3V DC, 0.59 A, 36 Cells, Open End

product price: $109.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Maximum Power Point 10 W
  • Cell Type Polycrystalline
  • Voltage @ Maximum Power Point 17.3V DC
  • Current @ Maximum Power Point 0.59 A
  • Overall Width 8.82 in
See all product information

Product Information

Dimensions

Overall Width 8.82 in
Overall Height 13.8 in
Overall Depth 0.98 in
Cable Length 9 ft

Details

Item Solar Panel
Maximum Power Point 10 W
Cell Type Polycrystalline
Voltage @ Maximum Power Point 17.3V DC
Current @ Maximum Power Point 0.59 A
Number of Cells 36
Connector Open End
Module Efficiency 9.5 %
Short Circuit Current 0.64 A
Green Environmental Attribute Product Contributes to Providing Renewable Energy
Operating Temp. Range -40 Degrees to 185 Degrees F
Max. System Voltage 1000V DC (TUV)/600V DC (UL)
Standards ETL Class I, Division 2, Groups A, B, C and D, UL Listed 1703
Power Tolerance +/-5%
Open Circuit Voltage 21.8 V
Weight 3.3 lb
Frame Yes
Includes Junction Box
Normal Operating Cell Temperature (NOCT) 48 Degrees C
Junction Box IP Rating IP65
Temperature Coefficient of PM -0.46%/ Degrees K
Maximum Operating Temperature 90 Degrees C
Minimum Operating Temperature -40 Degrees C
Frame Material Anodized Aluminum
Compatible with Series M-Series
Maximum Series Fuse Rating 10 A
Rated Snow/Wind Load 30 lb/sq ft
Compatible with Brand SolarTech
Maximum System Voltage 600V (UL)

Description

Solar Panel, Maximum Power Point 10 W, Number of Cells 36, Voltage @ Maximum Power Point 17.3 V, Current @ Maximum Power Point 0.59 A, Connector Open End, Cable Length 9 ft, Overall Height 13.8 in, Overall Width 8.82 in, Overall Depth 0.98 in, Compatible with Series M-Series, Includes Junction Box, Cell Type Polycrystalline, Compatible with Brand SolarTech, Weight 3.3 lb, Power Tolerance +/-5 Percent, Short Circuit Current 0.64 A
