This item is Discontinued.

Solartech Power Polycrystalline Solar Panel, 85 W, 34.5V DC, 2.48 A, 72 Cells, 4mm PV SPM085P-WP-N

Polycrystalline Solar Panel, 85 W, 34.5V DC, 2.48 A, 72 Cells, 4mm PV (Discontinued)

  • Mfr # SPM085P-WP-N
  • Zoro # G8118004
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SPM085P-WP-N
Zoro #
G8118004
UPC #
-
Country of Origin
Viet Nam

Dimensions

Overall Width
26.3 in
Overall Height
39.9 in
Overall Depth
1.38 in
Cable Length
3 ft
Depth
1 3/8 in
Width
26 5/16 in
Height
36 15/16 in

Details

Item
Solar Panel
Maximum Power Point
85 W
Cell Type
Polycrystalline
Voltage @ Maximum Power Point
34.5V DC
Current @ Maximum Power Point
2.48 A
Number of Cells
72
Connector
4mm PV
Frame
Yes
Operating Temp. Range
-40 Degrees to 185 Degrees F
Green Environmental Attribute
Product Contributes to Providing Renewable Energy
Power Tolerance
+/-5%
Standards
ETL Class I, Division 2, Groups A, B, C and D, UL Listed 1703
Short Circuit Current
2.62 A
Max. System Voltage
1000V DC (TUV)/600V DC (UL)
Weight
19.8 lb
Module Efficiency
12.6 %
Open Circuit Voltage
42.1 V
Includes
Junction Box
Minimum Operating Temperature
-40 Degrees C
Maximum Series Fuse Rating
10 A
Junction Box IP Rating
IP65
Compatible with Brand
SolarTech
Maximum Operating Temperature
90 Degrees C
Compatible with Series
W-Series
Frame Material
Anodized Aluminum
Rated Snow/Wind Load
30 lb/sq ft
Temperature Coefficient of PM
-0.46%/ Degrees K
Maximum System Voltage
600V (UL)
Normal Operating Cell Temperature (NOCT)
48 Degrees C
Nominal Output Power
85 W
Panel Max. Power Point Voltage
34.5V DC
Panel Max. Power Point Current
2.48 A

Description

Solar Panel, Maximum Power Point 85 W, Number of Cells 36, Voltage @ Maximum Power Point 34.5 V, Current @ Maximum Power Point 2.48 A, Connector MC4, Cable Length 3 ft, Overall Height 39.9 in, Overall Width 26.3 in, Overall Depth 1.38 in, Compatible with Series W-Series, Includes Junction Box, Cell Type Polycrystalline, Compatible with Brand SolarTech, Weight 19.8 lb, Power Tolerance +/-5 Percent, Short Circuit Current 2.62 A
