  9. Drum Pump, 12VDC, 1/4 HP, 60 Hz
Sotera Drum Pump, 12VDC, 1/4 HP, 60 Hz SS435B - main

Drum Pump, 12VDC, 1/4 HP, 60 Hz

  • Mfr # SS435B

  • Zoro # G1327943

product price: $1,365.99
/ea
Free Shipping & Returns

Key Features

For Use With
Caustics, Cleaners, Degreasers, Deionized Water, Diesel Exhaust Fluid, Solvents
Includes
1 in Ball Valve, 1 in Ball Valve Nozzle, 1 in Female Camlock Coupler with 1 in NPT Male Threads, 1 in NPT 90 Degrees Outlet Flange, 20 ft Battery Cable with Clips, 30A Fuse, 825 Digital Meter, Anti-Drip Tip
Max. Viscosity
3,000 cps
Motor Type
DC Permanent Magnet
Power Source
Electric
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SS435B
Zoro #
G1327943
UPC #
089404213025
Country of Origin
United States

Dimensions

Outlet Size
1"
Manufacturers Warranty Length
1 yr.
Hose Length
12 ft
Overall Length
22 1/2 in
Discharge Tube Outlet ID Size
1"
Inlet Size
1" NPT
For Container Size
55 gal
Hose Outside Dia.
1 in
Hose Inside Dia.
3/4 in

Details

For Use With
Caustics, Cleaners, Degreasers, Deionized Water, Diesel Exhaust Fluid, Solvents
Item
Electric Operated Drum Pump
Includes
1 in Ball Valve, 1 in Ball Valve Nozzle, 1 in Female Camlock Coupler with 1 in NPT Male Threads, 1 in NPT 90 Degrees Outlet Flange, 20 ft Battery Cable with Clips, 30A Fuse, 825 Digital Meter, Anti-Drip Tip
Max. Viscosity
3,000 cps
Motor Type
DC Permanent Magnet
Power Source
Electric
Wetted Materials
Fluorocarbon, Polypropylene, Santoprene, Stainless Steel
Voltage
12VDC
Motor Enclosure
TENV
Metered
Yes
Max. Flow GPM
12-15 gpm
Motor RPM
360 to 2600
HP
1/4
RPM
360 to 2600
GPM
13
Max. GPM for Water
15
Max. Pressure
15 psi
Piston Material
Santoprene
Max. Head
34 ft.
Application
Diesel Exhaust Fluid, Solvents, Cleaners, Degreasers, Deionized Water, Caustics
Max. GPM for Oil
12
Seal Material
Fluorocarbon
Max. Liquid Temp.
130 Degrees F
Hose Material
EPDM
Phase
1
Hz
60
pH Range
3.6 to 11.9
Housing Material
Glass Filled Polypropylene
DEF Compatible
Yes
Discharge Tubing Material
EPDM
Max. Temp.
130 Degrees F
Type
Diaphragm
Variable Speed
No
Diesel Exhaust Fluid Compatible
No
Includes Suction Tube
Yes
Max. Head - Pumps
34 ft
Not Recommended Chemicals
Acetic Acid (Glacial), Acetic Acid 20%, Acetic Acid 80%, Acetone, Ammonia (Liquids), Ammonium Hydroxide, Anhydrous Ammonia, Antifreeze (Coolant), Automatic Transmission Fluid, Biodiesel, Brake Fluid, Calcium Chloride, Chromic Acid 10%, Chromic Acid 30%, Chromic Acid 5%, Chromic Acid 50%, Citric Acid 50%, Cyclohexane, DEF, Deionized Water, Diesel Fuel, E85, Ethyl (Ethanol), Ethyl Acetate, Ethylene Glycol, Formic Acid, Fresh Water, Gasoline, Glycerin, Heptane, Hexane, Hydraulic Oils (Petroleum), Hydraulic Oils (Synthetic), Hydrochloric/Muriatic Acid (100%), Hydrochloric/Muriatic Acid (20%), Hydrochloric/Muriatic Acid (37%), Hydrofluoric Acid (20%), Hydrofluoric Acid (75%), Hydrofluoric Acid 100%, Isopropyl (Isopropanol), Kerosene, Lacquer Thinners, Methyl (Methanol), Methyl Chloride, Methyl Ethyl Ketone (MEK), Naphtha, Nitric Acid (10% Solution), Nitric Acid (20% Solution), Nitric Acid (50% Solution), Nitric Acid (Concentrated Solution), Paint, Paint Thinner, Pesticides, Phosphoric Acid (40% Solution), Potassium Hydroxide (50%), Salt Water, Sodium Bicarbonate (10%), Sodium Bisulfate, Sodium Bisulfite, Sodium Hydroxide/Caustic Soda (20%), Sodium Hydroxide/Caustic Soda (50%), Sodium Hydroxide/Caustic Soda (80%), Sodium Hypochlorite/Bleach (to 20%), Stoddard Solvent (Mineral Spirits), Sulfuric Acid (10% - 75%), Sulfuric Acid (75% - 100%), Sulfuric Acid (to 10%), Toluene, Trichlorethylene (50%), Turpentine, Xylene
Discharge Connection Type
NPT
Includes Discharge Hose
Yes
Housing Material - Pumps
Polypropylene
Includes Nozzle
Yes
Max. Fluid Temp.
130 Degrees F
For Container Type
Drum
Pump Connection Type
FNPT
Duty Cycle
Intermittent
Food Grade
No
Noise Level
77 db
Max. Flow Rate
13 gpm
Pump Connection ID
1 in
Compatible Chemicals
Fertilizers, Fungicides, Herbicides, Motor Oil
Discharge Tube Outlet OD
1 in
Runs Dry
Yes
Hose Tube Material
EPDM
Motor HP
1/4 hp
Full Load Amps
20.0 A
Includes Bung Adapter
No
Pump Connection OD
1 1/4 in
Frequency (Hz)
60 Hz
Hose Cover Material
EPDM
Discharge Tube Outlet ID
3/4 in
Nozzle Operation
Manual
Number of Phases
1
For Media Type
Fertilizers, Fungicides, Herbicides, Motor Oil
Gear Lube
NT
Max. Outlet Pressure
15 psi
Grease
NT
Rated Voltage
12V DC

Description

Electric Operated Drum Pump, Hose Inside Dia. 3/4 in, Max. Outlet Pressure 15 psi, For Use With Caustics, Cleaners, Degreasers, Deionized Water, Diesel Exhaust Fluid, Solvents, Rated Voltage 12V DC, Pump Connection ID 1 in, Hose Length 12 ft, Includes Bung Adapter No, Runs Dry Yes, Nozzle Operation Manual, Frequency (Hz) 60 Hz, Power Source Electric, Variable Speed No, Includes Discharge Hose Yes, Compatible Chemicals Fertilizers, Fungicides, Herbicides, Motor Oil, Discharge Connection Type NPT
