Speaker, Black, 20 Max. Wattage

Mfr # SM400I-BK
Zoro # G3925192

319.99

Free Shipping & Returns

Key Features

Type

Indoor

Standards

CE Compliant, RoHS, UL1480A

Indoor/Outdoor

Indoor

Enclosure Material

Plastic/Metal

Enclosure Color

Black

See all product information

Unlock 30-day payment terms

Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.

Create Account

Get 10% off your order

Specifications

Product Information

MFR #: SM400I-BK
Zoro #: G3925192
UPC #: -
Country of Origin: China

Dimensions

Overall Length (In.): 12
Overall Height (In.): 10
Tweeter Dia. (In.): 1 in
Woofer Dia. (In.): 4 in
Overall Width (In.): 9
Overall Height: 9 3/4 in
Overall Depth: 7 1/2 in
Overall Width: 7 in
Woofer Diameter: 4 in
Tweeter Diameter: 1 in

Details

Item: Speaker
Type: Indoor
Standards: CE Compliant, RoHS, UL1480A
Indoor/Outdoor: Indoor
Enclosure Material: Plastic/Metal
Enclosure Color: Black
Includes: Euroblock, Port Plug, Safety Cable, Terminal Weather Boot, U-Bracket
Sensitivity (dB): 86 dB
Weight (Lbs.): 8
Tweeter Composition: Aluminum
Impedance (Ohms): 4 ohm
Woofer Composition: Polypropylene/Butyl
Max. Wattage: 20 W
Power Taps @ 25V: 2
Watt (RMS): 20
Frequency Response: 100Hz to 22KHz
Transformer Settings: 25V/70V/100V
Power Taps @ 75V: 20
Number of Channels: 1
Mounting Style: Surface Mount
Dispersion - Horizontal: 125 Degrees
Enclosure Style: Backcan
Transformer Taps @ 25V: 2.5 W
Tweeter Material: Aluminum
Compatible Input Voltage: 100V, 25V, 70V
For Location: Indoor, Outdoor
Woofer Material: Polypropylene
Housing Material: ABS Glass Fiber
Transformer Taps @ Low Voltage: 4 ohm
Frequency Response - Minimum: 76 Hz
Includes Mounting Hardware: Mounting Hardware Included
Sensitivity: 83 dB
IP Rating: IP4X
Impedance: 4 ohm
Power Style: Passive
Housing Color: Black
Driver Configuration: 2-Way
Frequency Response - Maximum: 22 kHz
Output Wattage - RMS: 20 W
Transformer Taps @ 70V: 20 W
Dispersion - Vertical: 125 Degrees
Output Wattage - Peak: 35 W
Includes Transformer: Transformer Included

Description

Speaker, Indoor, Overall Height (In.) 10, Overall Width (In.) 9, Overall Length (In.) 12, Enclosure Color Black, Enclosure Material Plastic/Metal, Tweeter Dia. (In.) 1 in, Tweeter Composition Aluminum, Woofer Dia. (In.) 4 in, Woofer Composition Polypropylene/Butyl, 20 Watt (RMS), Max. Wattage 20 W, Sensitivity (dB) 86 dB, Impedance (Ohms) 4 ohm, Transformer Settings 25V/70V/100V, 2 Power Taps @ 25V, 20 Power Taps @ 75V, Frequency Response 100Hz to 22KHz, Weight (Lbs.) 8
