  11. THHN; THWN Building Wire, Copper, 10 AWG, 1C, White, Stranded, 50 ft
Southwire THHN; THWN Building Wire, Copper, 10 AWG, 1C, White, Stranded, 50 ft 22974083 - main

THHN; THWN Building Wire, Copper, 10 AWG, 1C, White, Stranded, 50 ft

  • Mfr # 22974083

  • Zoro # G307946701

product price: $65.15
/ea
Sold in multiples of 2 for $130.30

Key Features

Trade Designation
THHN; THWN
Wire Size
10 AWG
Conductor Material
Copper
Number of Conductors
1C
Wire Color
White
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
22974083
Zoro #
G307946701
UPC #
32886918070
Country of Origin
United States

Dimensions

Wire Size
10 AWG
Length
50 ft
Nominal Outside Dia.
0.165 in
Jacket Thickness (Mils)
5mils
Insulation Thickness (Mils)
20mils

Details

Item
Building Wire
Trade Designation
THHN; THWN
Conductor Material
Copper
Number of Conductors
1C
Wire Color
White
Jacket Color
White
Jacket Material
Nylon
Conductor Design
Stranded
Insulation Material
Thermoplastic
Voltage
600V AC
Temp. Rating
90°C
Standards
ASTM - B3; UL Standards 83 and 758; CSA C22.2 No. 75; NOM-ANCE 90° C; Federal Specification A-A-59544; National Electrical Code, NFPA 70; VW-1; FT1; RoHS/REACH Compliant
Stranding
19
Max. Amps
30
Applications
ApplicationTHHN copper conductors are primarily used in conduit and cable trays for services, feeders and branch circuits in commercial or industrial applications as specified in the National Electrical Code. Voltage for all applications is 600 volts.THWN- Wet locations not to exceed 75° C or dry locations not to exceed 90° C or locations not to exceed 75° C when exposed to oil
Construction
ConstructionSouthwire® THHN copper conductors are made with soft drawn copper. Combination-unilay stranding. The wire is covered with a tough heat and moisture resistant PVC insulation with an overall nylon jacket. Marked as THWN.
Allowable Ampacity At 75C
30

Description

50', 10 Stranded, White Building Wire, Type THHN, Nylon Jacketed, 90 Degrees Celsius, Copper, 600V, Plastic Spool

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
