Shop All Desiccant Dryers
Speedaire

Dryer, Desiccant

original price: $418.07
10% off
new price: $372.36
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Total Capacity - Air Treatment 2,300 cu ft
  • Max. Flow - Air Treatment 5 cfm
  • Connection Size - Air Treatment 1/4 in NPT
  • Dew Point - Air Treatment -4 Degrees F
  • Max. Incoming Pressure - Air Treatment 175 psi
See all product information

Product Information

Dimensions

Connection Size - Air Treatment 1/4 in NPT
Width (In.) 4 1/8 in
Bowl Size (Lb.) 1
Height (In.) 12 in
Overall Length 13 in
Outside Diameter 4 1/8 in
Air Outlet Size 1/4 in
Overall Height 4 in
Overall Width 4 in
Air Inlet Size 1/4 in

Details

Item Desiccant Air Dryer
Total Capacity - Air Treatment 2,300 cu ft
Max. Flow - Air Treatment 5 cfm
Dew Point - Air Treatment -4 Degrees F
Max. Incoming Pressure - Air Treatment 175 psi
ISO Class - Air Treatment 3
ISO Class 3
Bowl Rugged Metal
(F)NPT Inlet (In.) 1/4
Inlet/Outlet NPTF (In.) 1/4
Max. SCFM @ 100 PSI 5
Desiccant Material Silica Gel
Application Paint Spray
CFM 5
Item - Desiccant Dryers Desiccant Air Dryer
Max. Operating Temp. (F) 125 Degrees F
Total Capacity (Cu.-Ft.) 2300
(M)NPT Outlet (In.) 1/4
Dew Point (Deg. F) -4
Max. Operating PSI 175
Bowl Material Metal
Minimum Operating Temperature 35 Degrees F
Bracket Kit Included No
Filter Included No
Maximum Operating Temperature 125 Degrees F
Filter Element Compatibility HF5-12-4DPL
Filter Rating 15 micron
Number of Air Inlets 1
Air Outlet Gender Female
Air Inlet Gender Female
Body Material Aluminum
Standards ISO
Maximum Flow @ 100 psi 5
Bowl Capacity 1 lb
Number of Air Outlets 1
Maximum Flow Rate 5 cfm
Includes Modular Connection Kit
Maximum Operating Pressure 200 psi
Air Inlet Type NPT
Drain Type Automatic
Filtered Substance Dirt, Dust, Oil, Water
Maximum Ambient Temperature 100 Degrees F
Drain Included Yes
Air Outlet Type NPT
Weight 13 lb
Dew Point -40 Degrees F
Total Air Capacity 2,300 cu ft
Housing Material Aluminum

Description

Desiccant Air Dryer, ISO Class 3, Air Inlet Size 1/4 in, Air Inlet Type NPT, Maximum Flow Rate 5 cfm, Overall Length 13 in, Overall Width 4 in, Maximum Flow @ 100 psi 5, Maximum Operating Pressure 200 psi, Minimum Operating Temperature 35 Degrees F, Dew Point -40 Degrees F, Filter Rating 15 micron, Filter Included No, Air Inlet Gender Female, Air Outlet Gender Female, Air Outlet Size 1/4 in, Air Outlet Type NPT, Application Paint Spray, Body Material Aluminum, Bowl Capacity 1 lb
