  15. 30mm push button, Type K, pilot light, red LED light module, 12/14VAC/VDC, red plastic fresnel lens, NEMA 4, 13
Square D 30mm push button, Type K, pilot light, red LED light module, 12/14VAC/VDC, red plastic fresnel lens, NEMA 4, 13 9001KP32LRR31 - main

30mm push button, Type K, pilot light, red LED light module, 12/14VAC/VDC, red plastic fresnel lens, NEMA 4, 13

  • Mfr # 9001KP32LRR31

  • Zoro # G410839396

product price: $140.99
/ea
Free Shipping & Returns

Key Features

Lamp Type
LED
Terminal Connection
Screw Clamp
Lens Material
Plastic
Size
30 mm
Lens Type
Fresnel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
9001KP32LRR31
Zoro #
G410839396
UPC #
785901771210
Country of Origin
Mexico

Dimensions

Size
30 mm
Width
54 mm
Height
70 mm
Mounting Diameter
30 mm
Overall Width
2.13 in
Overall Height
2.76 in
Panel Cutout Diameter
30 mm
Overall Depth
1.65 in
Manufacturer Warranty Length
18 mo

Details

Item
Pilot Light
Lamp Type
LED
Terminal Connection
Screw Clamp
Lens Material
Plastic
Lens Type
Fresnel
Body Material
Metal
Standards
CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, IEC 61140, JIS C852, JIS C8201-1, JIS C8201-5-1, UL 508
IP Rating
IP66
Short-Circuit Protection
10 A cartridge fuse IEC 60947-5-1
[Uimp] Rated Impulse Withstand Voltage
2.5 kV IEC 60947-1
Bezel Material
metal
Shape of Screw Head
cross slotted
Light Source
LED
Ambient Air Temperature For Operation
-25-70°C
Nema Degree of Protection
NEMA 1, NEMA 12, NEMA 13, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 6
Device Short Name
9001K
Cap/Operator or Lens Colour
red
Operating Position
any position
Ambient Air Temperature For Storage
-40-70°C
Shock Resistance
50 gn IEC 60068-2-27
Ip Degree of Protection
IP66 IEC 60529
Light Source Colour
red
Range of Product
Harmony 9001K
Light Block Supply
direct 12 V AC/DC
Protective Treatment
TC
[Us] Rated Supply Voltage
12...14 V
Connections - Terminals
screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
Bulb Base
BA 9s
Overvoltage Category
class II IEC 61140
Tightening Torque
0.8-0.8 N.m IEC 60947-1
[Ith] Conventional Free Air Thermal Current
10A
Shape of Signaling Unit Head
round
[Ui] Rated Insulation Voltage
250 V 2)IEC 60947-1
Vibration Resistance
7 gn 2-500 Hz)IEC 60068-2-6
Product or Component Type
pilot light
Series
9001K
Voltage Rating - Maximum
14 V
Lamp Voltage - Maximum
12 V AC/DC
Lamp Color
Red
Includes Lamp Module
Lamp Module Included
Includes Push-To-Test
No Push-To-Test Included
Lens Color
Red
NEMA Enclosure Rating
1, 12, 13, 2, 3, 3R, 4, 6
Includes Lens
Lens Included
Resistance Properties
Shock Resistant, Vibration Resistant
Operator Illumination
Illuminated

Description

Pilot Light, Lamp Type LED, Terminal Connection Screw Clamp, Lens Material Plastic, Lens Type Fresnel, Body Material Metal, IP Rating IP66, Standards CSA C22.2 No.14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, IEC 61140, JIS C852, JIS C8201-1, JIS C8201-5-1, UL 508
