Miniature Circuit Breaker, 15A, 1 Poles 10kA
Mfr # HOMT1515CP
Zoro # G2905293
product price:
$
25.89
/ea
Key Features
Series
HOMT
Amps
15 A
Number of Poles
1
AC Voltage Rating
120/240V AC
Circuit Breaker Type
Tandem
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- HOMT1515CP
- Zoro #
- G2905293
- UPC #
- 47569071058
- Country of Origin
- Mexico
Dimensions
- Width
- 1 in
- Depth
- 2.98 in
- Height
- 3.13 in
Details
- Item
- Miniature Circuit Breaker
- Series
- HOMT
- Amps
- 15 A
- Number of Poles
- 1
- AC Voltage Rating
- 120/240V AC
- Circuit Breaker Type
- Tandem
- Circuit Breaker Mounting Style
- Plug In
- Max. AIR Rating
- 10kA
- Trip Type
- Thermal Magnetic
- Terminal Connection
- Lugs
- DC Voltage Rating
- Not Rated
- Product Certifications
- UL Listed
- Poles Description
- 1P
- Tightening Torque
- 4.0-4.0 N.m 2.5-6 mm2² (AWG 14...AWG 8)
- Circuit Breaker Application
- HACR rated
- Ambient Air Temperature For Operation
- 40 2°C
Description
The Square D by Schneider Electric Homeline Single-Pole Tandem Circuit Breaker consists of (2) single-pole, 15 amp breakers in 1 pole space. It is used for overload and short-circuit protection of your electrical system. This breaker is compatible with Homeline load centers and CSED devices. A The ANSI-certified and UL-listed unit is rated for 120/240V AC and 10000 AIR. A Homeline circuit breakers are built with the same Square D brand quality you have come to expect at a price that makes them the best value in their class. A Homeline circuit breakers are the best in class. Designed exclusively for the residential market, Homeline products offer everything you need to distribute electricity throughout your home.
- • Homeline 2-15 amp one-pole tandem circuit breaker
- • Plug-on design, easy to install
- • Compatible with Homeline load centers and CSED devices
- • 120/240 volt AC
- • 10000 AIR
- •
